Specifications
Brand Name :
OURS ULTRASONIC
Certification :
CE AND FCC
Place of Origin :
Shenzhen China
MOQ :
1SET
Payment Terms :
T/T, Western Union PAYPAL
Supply Ability :
10000set
Delivery Time :
1-5days
Packaging Details :
Carton box or plywood box
Model Number :
ARS-DLB120
Price :
USD25-USD45
power :
50W-150W
frequency :
28khz and 40khz
Voltage :
110V or 220V
Ultrasonic Power Box :
Ultrasonic Generator
Specification :
CE and FCC
Machine Type :
Industrial Ultrasonic Cleaner
Application :
Ultrasonic Generator PCB for Ultrasonic Cleaner parts
keyword :
Ultrasonic Generator PCB
Description

Piezoelectric Ceramic CE type with heatingUltrasonic PCB board fun40khz/28k 120W Ultrasonic Cleaner parts

Piezoelectric Ceramic CE type with heatingUltrasonic PCB board fun40khz/28k 120W Ultrasonic Cleaner parts

Piezoelectric Ceramic CE type with heatingUltrasonic PCB board fun40khz/28k 120W Ultrasonic Cleaner parts

Product features:
1. All the power output components IGBT are imported devices, with the advantages of small size, high power and fast response.
2, power -pipe: adopt imported Japanese Toshiba 90A/1200V import pipe to eliminate the possibility of burning pipe.
3, the latest excitation control circuit, the output power of up to 93%, so that the ultrasonic cavitation density has been greatly improved.

The ultrasonic generator also called ultrasonic power supply, electronic box and ultrasonic controller. It is an important part of high power ultrasonic system.

Features :
Soft start, short circuit protection, leakage protection and overload protection. The power is adjusted at 0-100%.
Pulse power control to reduce electromagnetic interference and enhance the stability of multiple ultrasonic generators.
Unique anti-corrosion design, to ensure that the product to adapt to a variety of environments.
Specification :

Type Frequency Power Dimension
(mm)		 Transducer numbers
ARS-DLB50W 25khz,28khz,33khz,40khz 50W 132×85×45mm 1 piece
ARS-DLB60W 25khz,28khz,33khz,40khz 60W 132×85×45mm 1 piece
ARS-DLB100W 25khz,28khz,33khz,40khz 100W 132×85×45mm 1-2 pieces
ARS-DLB120W 25khz,28khz,33khz,40khz 120W 132×85×45mm 1-2 pieces
ARS-DLB150W 25khz,28khz,33khz,40khz 150W 132×85×45mm 1-3 pieces
ARS-DLB200W 25khz,28khz,33khz,40khz,80khz,100khz,135khz 200W 180×130×60mm 4 pieces
ARS-DLB300W 25khz,28khz,33khz,40khz 300W 180×130×60mm 6 pieces
ARS-DLB400W 25khz,28khz,33khz,40khz 400W 180×130×60mm 8 pieces
ARS-DLB500W 25khz,28khz,33khz,40khz 500W 180×130×60mm 10 pieces
ARS-DLB600W 25khz,28khz,33khz,40khz 600W 180×130×60mm 12 pieces

Ultrasonic PCB generator could to 2400W,welcome send the enquire

200W-600W Ultrasonic PCB frequency adjustable,display board is optional

Above ultrasonic PCB generator 110V-120V or 220V-240V are available,contact with us during your order with detail request
