28khz/40khz ultrasonic cleaner machine parts 2000Watt ultrasonic cleaner machine price for Parts Bearings
1. The electrolytic cleaning system emits gas to the metal surface and removes dirt from the metal surface with the effect of sauna.
2. Reduce the metal to the original copper green and restore the original beauty of the metal.
3. Even complex shapes can remove dirt.
4. Clean and decontaminate completely and accurately.
5. It has good rust-removing and rust-preventing effect.
6. Save an hour more than manual cleaning
7. It is more environmentally friendly and safer than using organic solvents. It greatly reduces the rate of deterioration after washing.
Cleaning Principle
Using electrolysis, the object produces positive and negative molecules by the action of electric current. Under the catalysis of oxygen and hydrogen produced by metal surface, the dirty part is decomposed quickly, stripped and floated.
Using the cavitation effect of ultrasound, numerous small bubbles are produced to collide with the object. The dirt on the workpiece is blasted by impact, so that the dirt can be peeled automatically.
Special solutions are used to decompose the fouling rapidly by sufficient chemical effects.
Effective removal of oil, rust, sulfide, gas, plastic carbon deposits and other dirt on the mould
Mould cleaning machine for mould fouling can play a good cleaning effect, and zero damage to the mould itself.
Variety classification
Mold cleaning machine varieties are: simple ultrasonic cleaning machine, semi-automatic electrolytic mould cleaning machine, automatic electrolytic mould cleaning machine.
Pure ultrasonic cleaning machine: It is a kind of technology that uses ultrasonic cavitation. Through the principle of vibration emission of ultrasonic transducer, it can simply remove the oil stain on the surface of the mould. The cleaning effect is not thorough, and the cleaning and maintenance of the precision mould need not be considered.
Electrolytic Mould Cleaning Machine: Using electrolysis, the fouling is produced by the action of electric current. Through the catalytic action of oxygen and hydrogen generated on the metal surface, the fouling part is decomposed rapidly, stripped and floated out, and the fouling is decomposed rapidly by using special solution through full chemical effect. Effective removal of oil, rust, sulfide, gas, plastic carbon deposits and other dirt on the mold. The best choice of mould cleaning and maintenance.
Type | Internal size L*W*H (mm) | Outsize mm L*W*H (mm) | Frequency (Khz) | Power (W) | Heating (W) | Total power(W) | voltage |
ARS-DQXJ-1006 | 280×210×210 | 320×250×350 | 20,28,33,40,80,130 | 300 | 1000 | 1300 | 220V |
ARS-DQXJ-1012 | 400×310×280 | 520×430×600 | 20,28,33,40,80,130 | 600 | 3000 | 3600 | 220V |
ARS-DQXJ-1018 | 490×360×320 | 610×480×675 | 20,28,33,40,80,130 | 900 | 3000 | 3900 | 220V |
ARS-DQXJ-1024 | 630×430×320 | 740×550×675 | 20,28,33,40,80,130 | 1200 | 4000 | 5200 | 220V |
ARS-DQXJ-1030 | 630×530×320 | 750×650×675 | 20,28,33,40,80,130 | 1500 | 4000 | 5500 | 220V |
ARS-DQXJ-1036 | 680×530×360 | 800×650×700 | 20,28,33,40,80,130 | 1800 | 5000 | 6800 | 220V |
ARS-DQXJ-1040 | 680×570×400 | 830×710×735 | 20,28,33,40,80,130 | 2000 | 5000 | 7000 | 220V |
ARS-DQXJ-1041 | 730×570×450 | 880×710×735 | 20,28,33,40,80,130 | 2400 | 6000 | 8400 | 220V |
ARS-DQXJ-1042 | 790×670×510 | 940×765×785 | 20,28,33,40,80,130 | 3000 | 6000 | 9000 | 380V |
ARS-DQXJ-1043 | 850×770×570 | 990×820×785 | 20,28,33,40,80,130 | 4000 | 7000 | 11000 | 380V |
ARS-DQXJ-1044 | 910×820×620 | 1050×880×840 | 20,28,33,40,80,130 | 5000 | 7000 | 12000 | 380V |
ARS-DQXJ-1045 | 960×870×680 | 1100×940×920 | 20,28,33,40,80,130 | 8000 | 8000 | 16000 | 380V |
ARS-DQXJ-1046 | 1100×930×730 | 1160×1000×980 | 20,28,33,40,80,130 | 10000 | 8000 | 18000 | 380V |
28khz/40khz ultrasonic cleaner machine parts 2000Watt ultrasonic cleaner machine price for Parts Bearings
