100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale
100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale
100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale
100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale
100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale
100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale
Specifications
Brand Name :
NVK
Model Number :
NVK-IS
Certification :
OIML
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western union, negotiation
Supply Ability :
1000/month
Delivery Time :
3-7 days, depends on quantity
Packaging Details :
Nude or Wooden Packing
Power supply :
220v
Display :
LED/LCD
Rated load :
10-200ton
Product name :
10-200 ton weighbridge truck scale
Color :
Customized
Material :
High Quality Steel
Main beam thickness :
6/8mm option
Load cell :
4 pcs shear beam load cell
Description

100 Ton Industrial Electronic Large Weighbridge High Quality Steel Truck Weighing Scale

1. Comprehensive technical parameter

Accuracy class: OIML III
Weighing range: 10 ~ 200t
Length of platform assembly: 6 ~ 24m
Max transmitting distance of analog signal: 100m
Max transmitting distance of digital signal: 1000m
Platform width: 3 / 3.4m
Operating power supply: 240 / 220 / 110VAC, 50 / 60Hz
Safety overload: 130% Max
Working temperature: -10 ~ +40°C (indicator)
-30 ~ +65°C (scale body)
Relative humidity: < 95%

Note: The lowest working temperature of scale body can be down to -40°C according to user’s demand

100 Ton Electronic Digital Weighing Scale , Steel Truck Weigh Scale

2. Features of digital truck scales
1). Numeral transformation technology and compensation
The Inner part of the weighing load cell contains module conversion device and CPU processing unit.
Auto-compensation with digital technology to the parameter of load cell such as non-linearity, temperature, etc.
Free of calibrating for the scale if the load cells are replaced.
2). With the calibrating and digital technology, bias-load (four corners) calibration of the truck scale can be completed only once.
3). Digital communications technology
The central line structure can be used by several weighing load-cells (up to 32) in the same system.
RS485 interface is used and long-distance signal transmission is possible, with the transmission distance not less than 1000m.
Output signal at 3~4V strengthens the capability of anti-interference and lightening protection of the system.
4). Intelligent technology
The parameter of the load cell can be changed according to the orders.
Different wave-filtering ways can be adopted according to different situations.
5). Module, standard and series scale body, multiunit assembly
6). Digital load cell of full-sealing column and laser-welded stainless steel, with accuracy of C3, strong water-proof and anti-corrosive function
