1 Channel HDMI Mini 1080P H.265 IPTV Encoder
1 Channel HDMI Mini 1080P H.265 IPTV Encoder
1 Channel HDMI Mini 1080P H.265 IPTV Encoder
1 Channel HDMI Mini 1080P H.265 IPTV Encoder
1 Channel HDMI Mini 1080P H.265 IPTV Encoder
1 Channel HDMI Mini 1080P H.265 IPTV Encoder
Specifications
Brand Name :
DIGITOVISION
Model Number :
DGTE-HHI-001
Place of Origin :
CHENGDU
MOQ :
1 SET
Price :
$280~$330
Payment Terms :
T/T, Western Union, MoneyGram, T/T, D/P, D/A, L/C
Supply Ability :
1000/WEEK
Packaging Details :
1SET/CTN
Product Name :
1 Channel HDMI Mini 1080P H.265 IPTV Encoder
Product ID :
DGTE-HHI-001
Price Range :
$280~$330
Input :
HDMI (SDI) or HDMI+AV optiaonal
Output :
IP output with HTTP/RSTP/RTP/RTMP/UDP/ONVIF/HLS
Encoding :
H.265/H.265
Control :
Web-server
Description

1 Channel HDMI Mini 1080P H.265 IPTV Encoder

Outline

HDMI Encoder is a professional audio and video encoding products, which support 1-channel audio and video capture features high-definition HDMI, 1 3.5MM independent audio interface acquisition, dual streaming H.265/ H.264 encoded output format, audio MP3, AAC formats. It could be freely adjusted according to the need. The device is highly integrated, cost-effective. Support HTTP / RTSP / RTP / RTMP / UDP protocols.It is easy to install, plug-play, and there is no computer hardware compatibility issues.

Features

1.Compatible to different network protocol: RTSP/RTP/RTMP/HTTP/UDP/ONVIF/HLS unicast and multicast( RTMP support adding users and changing passwords)

2. Support Main TS stream and the sub TS stream use in different network protocols for transmission

3. HDMI input,H.265 The latest architecture

4.1 RJ 100M / 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol

5.Easy operation with Web management

6. OSD rolling, images superimposing

7. DHCP gaining IP automatic, One-key recovery, upgrade and remote maintenance

8.Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering

9.Support build-in or external methods, support left and right sound channel, support audio gain, be able to turn volume individually

10.Low power consumption design

11.Reliable and Cost-effective, Free Unlimited Tech Support and 3 Years warranty

1 Channel HDMI Mini 1080P H.265 IPTV Encoder

Technical Parameter

Product model HDMI Encoder
Input 1 channel HDMI input, 1 channel 3.5MM channel audio input
Output 1 channel IP signal output
Video Input resolution 1920x1080p/1920x1080i/1280x720p/720*576i/720*576p /640*480iAnd other conventional resolution
Coding standard H.265/H.264
Coding level

H.265 MAIN PROFILE

H.264 BASELINE PROFILE

H.264 MAIN PROFILE

H.264 HIGH PROFILE

Encoded size

 640*360~1920*1080(Can customize)
Video bit rate Rate control: CBR/VBR 16KBIT/S~12MBIT/S
Video frame rate 30
OSD Character, images
Audio Input selection 1 channel embedded audio hdmi, 1 channel 3.5MM independent audio support audio gain
Audio coding AAC/MP3
Audio bit rate 64Kb/s~384Kb/s
Sampling rate 32000,44100,48000 etc

IP

Output

 1 RJ 100M / 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol
System Network protocol Supports HTTP, RTSP, RTMP, UDP, multicast, unicast
Configuration management Support IE configuration, remote upgrade
General Power supply 12V~2A
power consumption 5W
Size 103mm * 70mm * 25mm(length*width*height)
Operating temperature -20℃+ 60℃
Working humidity <90%,Non-condensing
Weight 1 KG
