General Purpose Thermostats (Non-Ex) Thermostats For Non-Hazardous Areas FIX THERM 96 MODEL GTH Thermostat ELECTRICAL THERMOSTAT FIX THERM96 GENERAL PURPOSE MODEL GTH */*
General Purpose Thermostats (Non-Ex) Thermostats For Non-Hazardous Areas FIX THERM 96 MODEL GTH Thermostat ELECTRICAL THERMOSTAT FIX THERM96 GENERAL PURPOSE MODEL GTH */*
Specifications
Brand Name :
condor
Model Number :
THERMOSTAT FIX THERM96 GENERAL PURPOSE MODEL GTH */*
Place of Origin :
Mauritius/Netherlands
MOQ :
1pcs
Price :
EURO/USD/HKD
Payment Terms :
T/T
Delivery Time :
2-4 weeks
Packaging Details :
carton
Housing Material :
Anodized Aluminium
Voltage :
6A / 240 VAC
cable :
3x 0,75 sqmm
Material cable :
non-braided silicone cable
Standard length :
ca. 1 mtr., other lengths optional
Other lengths :
on request
Overall dimensions :
ca.30×49 mm (diameter xH)
weight :
ca. 160 g.
Switch :
SPST
Set-point tolerance :
+/- 3°C
Hysteresis :
ca. 2°C
Features :
Setpoints up to 60°C
Power Source :
Electric
color :
black
Mounting bracket :
available (B)
Description

Description

1 Application

For Non-Hazardous areas the General Purpose FixTherm96 thermostats are very suitable. Often used as maximum thermostat in instrumentation cabinets with space heating, to protect the equipment from overheating. Or as a minimum thermostat with space heating to protect from freezing.
In short, temperature maintenance.

  • Prevention of overheating
  • Freeze protection
  • Anticondensation

2 Features and Advantages

  • Setpoints up to 135°C
  • Accurate set-point – (N.C. contact)
  • Small hysteresis
  • Anodized aluminium housing ( Stainless steel housing available)
  • Inside grounding
  • Can be used for 110 / 240 VAC/DC

3 Remarks

  • The housing is made from anodized aluminium. When required in other applications, e.g. analyzers, it is normal practice to use our Space-Heaters in combination with our Fix-Therm96 thermostats (range from 10°C up to
    130°C).
  • The FixTherm96 can also be used for cooling purposes e.g. FixTherm96 TH-10/5F (N.O. contact).

4 Range

  • GTH-10/5 – going up with 5°C each time e.g. 10/5 – 15/10 – 20-15 etc. up to 130°C maximum.

5 Technical data

Housing Anodized Aluminium
Current / voltage 6A / 240 VAC
Cable 3x 0,75 sqmm
Material cable non-braided silicone cable
Standard length ca. 1 mtr., other lengths optional
Overall dimensions ca.30×49 mm (diameter xH)
Weight ca. 160 g.
Switch SPST
Set-point tolerance +/- 3°C
Hysteresis ca. 2°C
Mounting bracket available (B)
