Mounting Height:10-50m, This light is specially designed for outdoor places,
especially for high mast, stadium, sports field, hall, airport, square, etc. The adjustable brackets as well as different beam angle can meet different lighting requirement.
Technical parameter | ||||||
Lamp Model Number | GY350TG | |||||
Lamp Power | 300W | 400W | 500W | 600W | 800W | 1000W |
Module Qty | 4 | 5 | 6 | 8 | 10 | 12 |
Input Voltage | AC100~240V/277V (50~60Hz) | |||||
Lighting Efficiency | ≥120LM/W | |||||
Beam Angle | 30°/60°/90° | |||||
Power Factor | ≥0.95 | |||||
CRI | Ra70/80 | |||||
Color Temperature(K) | 3000~6500K | |||||
IP Grade | IP65 | |||||
Working Temperature(℃) | - 40 ~50 | |||||
Working Humility(RH) | 0 ~90% | |||||
Lamp Size (mm) | 405*415*173 | 405*520*173 | 405*625*173 | 765*415*173 | 765*520*173 | 765*625*173 |
Net Weight(KG) | 5.9 | 7.4 | 9.3 | 11.9 | 15 | 18.5 |
Material | Die Casting Aluminum + PC Lens |
