Working Theorying:

Alex 755nm Wavelength--For the widest range of hair types and color, especially light-colored and thin hair. Effective for superficially embedded hair in areas such as the eyebrows and upper lip.

808nm has a moderate melanin absorption level making it safe for darker skin types. while moderate tissue depth penetration makes it ideal for treating the arms, legs, cheeks and beard.

Yag 1064nm Wavelength--Specialized for darker. At the same time, the 1064nm offers the deepest penetration of the hair follicle, allowing it to target the Bulb and Papilla, as well as treat deeply embedded hair in areas such as the scalp, arm pits and pubic areas.

It is performed using gold standard and upgraded triple wavelength: “755nm+808nm+1064nm” diode laser technology, with energy penetrates deep into the dermis with high average power and a rapid 10 pulse-per-second repetition rate to heat the hair shaft and hair follicle, rather than destroy the oxygen organization around hair follicle.

Meanwhile, contacting surface cooling technology applied on the Sapphire Dual-Chill Tip can eliminate the heat effect attributed to optical energy, greatly improving both the treatment performance safety.

IPL/HR System
Fast hair removal stands for Super Hair Removal, a technology of permanent hair removal that is having a sweeping success. The system combines laser technology and the benefits of the pulsating light method achieving practically painless results. Even hairs that until now have been difficult or even impossible to be removed can now be treated. "In Motion" represents a breakthrough in permanent hair removal with light technology. The treatment is more pleasant than with the conventional systems and your skin is better protected.

Laser Picosecond :

The energy of Q-Switched ND:YAG Laser can be absorbed by the blue and black melanin.Utilizes the explosive effect of
the Picoseond laser, which permeates through the epidermis into the dermis containing the pigment mass. The laser pulses in nanosecond, super high energy.The melanin will be fragmented so small that they can be metabolized by the lymphatic system or be egested out of the body.Thus the tattoo or other pigmentations will be removed without injury to normal tissue.The treatment is safe and convenient without downtime or side effects.

Picosecond Laser Introduction:

The PicoSecond Laser uses ultra-short pulses (one trillionth of a second in length) to hit the melanin with a great pressure, the melanin shatters into tiny dust-like particles. Because the particles are so small, they are more readily absorbed and eliminated by the body. This can mean better clearance of the melanin and less treatments overall.

PicoSecond Laser is a quick and easy non-surgical, non-invasive laser skin treatment for the body including chest or decollete, face, hands, legs, and more.

Picosecond laser machine make tattoo & pigment removal treatment process from 5 to 10 times reduced to 2 to 4 times, greatly reduce the treatment and recovery time, with fast and obvious effect. Minimized Risk and Minimal Discomfort: the ultra-short pulses also optimize the delivery of energy to the targeted ink particles, which are more readily absorbed and eliminated by the body. It will significantly reduce melanin precipitate phenomenon. Meantime, the least amount of heat gets transferred into the skin.

Handle and Filters

Equipped with 4 filters can removal all color tattoos and pigment. There are several stages for tattoo removal treatment, like red tattoo, you can use 532nm filter to do treatment, after one treatment it will become gray, then you can use 1064nm filter to remove tattoo totally.

532nm filter main for slight color tattoos, like red and green etc.

1064nm filter main for dark color tattoos, like black and blue etc.

755nm filter can do all colors tattoo. It used Honeycomb Focused technology gently protect skin from damage during treatment. Comfortable & Safe.

1320nm filter need combine carbon cream to use, main for skin cleaning, skin rejuvenation. One treatment equal to 50 times facial mask treatment!

Applications

808 Diode:

1.Treat all kind of hair color from black hair to white hair

2.Treat all skin types

3.No pain and shorter treatment sessions

4.Effective and safe treatment for permanenting hair removal

Laser Picosecond:

1.Pigment dispelling.

2.Tattoo removal: can remove black, blue, brown and red tattoo pigments on eyebrow, eyeline ,
lipline and other parts of the body.

3.Skin rejuvenation:laser facial, large pore reduction,face whitening.
4.Eliminate the age pigment, spot, birthmarks, and pigment changes etc.

IPL:

1. Permanent hair removal

2. Skin rejuvenation

3. Reduction of pigmented lesions

4. Wrinkle removal

5. Acne Therapy

6. Freckle, vascular lesions and facial blemish removal

Parameter:

Technology: Diode laser(755nm+808nm+1064nm)+ IPL/S + Q-switched Nd: YAG Laser

Wavelength: Diode laser(755nm+808nm+1064nm);
IPL: 480nm/530nm/640nm
Nd:YAG Laser: 1064nm/532nm/1320nm

Diode laser Pulse width: 10-300ms

Cooling Level: 1-5 Levels (-10 ° C - 5 ° C)

Nd:Yag laser Pulse width: <10ns

Diode laser Pulse width: 10-300ms

Working time: Continuously 18 hours without stop

Display: 10.4 inch true color touch screen

Spot Size: Diode laser:13mm*16mm ; IPL: 15*50mm

Cooling system: semiconductor + water circulation + air radiator cooling with condenser
