1R1G1B 5mm 320x10mm Outdoor Fixed LED Display
1R1G1B 5mm 320x10mm Outdoor Fixed LED Display
1R1G1B 5mm 320x10mm Outdoor Fixed LED Display
1R1G1B 5mm 320x10mm Outdoor Fixed LED Display
Specifications
Brand Name :
shervin
Model Number :
SST-F6
Certification :
CCC.CE.ROHS
Place of Origin :
China
MOQ :
1 square meter
Price :
300-800 usd/sets
Payment Terms :
L/C, D/A, D/P, Western Union, Western Union
Supply Ability :
5000square meter per month
Delivery Time :
within 5days after your payment
Packaging Details :
wooden box and Pearl cotton inside
Module size :
320x10mm
Display Function :
video
color :
full color
Cabinet size :
640x640mm
Pixel Pitch :
5mm
Power Supply: :
Meanwell
Description

3 years warranty high definition and brightness full color outdoor fixed led display for outdoor publicity usage

The coverage is wide and the audience is large. Outdoor large LED displays are generally installed in a relatively high place, the screen is relatively large, and the viewing angle is also large.

Under normal circumstances, the video is still clearly visible from a 140 degree angle in the horizontal direction, which makes the large LED screen Display content can cover a wider range and reach more audiences.

This major feature is also one of the reasons why many businesses are willing to choose outdoor large LED displays for advertising content.


the detailed specification of outdoor led display as follows.

The outdoor full color led display parameter
NO.ItemP3.91P4P5P6P8P10
1pixel pitch (Millimeter)3.91456810
2Led lampSMD2727SMD3535SMD3535SMD3535SMD3535SMD3535
3Pixel density654106250040000277771562510000
4Module size250X250256X128320X160192X192256X128320X160
5Module resolution64X6464X3264X3232X3232X1632X16
6Scan mode1/81/81/81/81/81/8
7Cabinet size500X1000768X768960X960960X9601024X1024960X960
8Cabinet resolution128X256192X192192X192160X160128X12896X96
9Brightness7000cd7000cd7000cd7000cd7000cd7000cd

SpecificationDrive methodmodule sizepixelPixel compositionPoint densityCabinet size / length and width
P3.91die cast aluminum(SMD)1/8 scan250*250mm64*641R1G1B65410500*1000MM
P3.91iron cabinet(SMD)1/8 scan250*250mm64*641R1G1B654101000*1000MM
P4(SMD)die cast aluminum1/8 scan256*128MM64*321R1G1B62500512*512MM
P4(SMD)1/8 scan256*128MM64*321R1G1B62500768*512MM
P4.81die cast aluminum(SMD)1/13scan250*250mm52*521R1G1B43222500*1000MM
P5(SMD)1/8 scan320*160MM32*321R1G1B40000960*960MM
P5(SMD)die cast alumiunm1/8 scan320*160MM64*321R1G1B40000640*640MM
P5.95(SMD) die cast aluminum1/7 scan250*250mm42*421R1G1B28246500*1000MM
P6(SMD)1/8 scan192*192MM32*321R1G1B27778960*960MM
P6(SMD)die cast aluminum1/8 scan192*192MM32*321R1G1B27778576*576MM
P6.67(SMD)die cast alumium1/8 scan320*160MM48*241R1G1B22478640*640MM
P8(SMD)1/4 scan256mm*128mm32*161R1G1B156251024mm*768mm
P8(SMD)die cast aluminum cabinet1/4 scan320mm*160mm40*201R1G1B15625640mm*640mm
P10(DIP)1/4 scan160mm*160mm16*161R1G1B10000960mm*960mm
P10(SMD)1/4 scan320mm*160mm32*161R1G1B10000960mm*960mm
P10(SMD)1/2 scan320mm*160mm32*161R1G1B10000960mm*960mm
P10(SMD)die cast aluminum1/4 scan320mm*160mm32*161R1G1B10000640mm*640mm
P16(DIP)Static full color256mm*256mm16*161R1G1B39061024mm*1024mm
P20(DIP)Static full color320mm*160mm16*81R1G1B25001280mm*960mm


1R1G1B 5mm 320x10mm Outdoor Fixed LED Display

1. All the products owners purchased from shervin possess the following rights:
A: Unconditional replacement within 7 days. B: 3 years warranty for maintenance.
2. The repaired products will be sent back at shervin cost to customer within 7 days( from the date we receive the defective products at customers cost).
3. 100% authentic strict assessment, for you to select high visibility, quality, good service goods; 10 times refund in case any fake were found.
4. 12 hours after-sale service shervin professional services team promises to resolve any problems related to the use, installation and configuration of the product within 12 hours.
5. 30 days price protection If the price of the products as what you purchased is getting lower within 30 days, shervin will refund the price difference.
6. Public welfare plane 2‰ of the amount of each order will be donated to public welfare organizations for the disabled.
