Comfortable Car Brake Pads Heat Resistance ISO9001 Certificated

Zhengzhou Baiyun Industrial Co., Ltd., since 1977, is a national high-tech enterprise with main products of brake friction material and brake products. For more than 40 years, Baiyun focus on the R&D, production and selling of brake linings & pads for commercial vehicles and passenger cars, fighting for human traffic braking safety. Till now, Baiyun has become an important supporting supplier and partner of many famous domestic and overseas auto brands. Baiyun has also reached long term strategic cooperation with many famous domestic and overseas auto parts distributors.
Zhengzhou Baiyun Industrial Co., Ltd., is one of the leading auto friction braking enterprise in China, Top 10 enterprises of China Friction Material Industry and member of friction industry association. Baiyun has passed ISO9001 Quality Management System and IATF16949 Auto Industry Quality System Certification. Long-term cooperation is established with international authoritative test organizations such as America LINK and GREEN to test Baiyun brakes regularly. There are more than 1000 models brakes of Baiyun have obtained E-mark certification till now.

Advantage of Baiyun Car Brake Pads
1). Excellent formula. Various formulas are suitable for different models and road conditions
2). Equipped with commercial vehicle bench test bench and passenger vehicle bench test bench, 1:1 simulated real brake friction performance test, each formula and product for strict testing.
3). Automatic large scale batching system with accurate matching.Ensure uniform quality of ingredients.
4), the equal ratio press presses, presses the finished product density unification, the quality is consistent.
5), automatic unmanned operation press, automatic packing and steel back, automatic flattening, automatic pressing, eliminate the error rate of manual operation, to ensure the quality of finished products.

BAIYUN MAKES IT GREENER FOR BEST-IN-CLASS PERFORMANCE WITH THIS TECHNOLOGICAL BREAKTHROUGH
Green materials for a greener product & a significant reduction of fine particles emissions
Lower Noise
Much more safety
Best-in-class performance results

AS GREAT AS A BAIYUN PREMIER PAD, MINUS THE COPPER
BAIYUN brake tested on 6 popular vehicles models: consistency of performance results ascertained
Up to 17% more stopping power than competitors' brands on selected vehicles makes the BAIYUN pad the best product with a technical innovation already approved and adopted by vehicle manufacturers.

Disc Brake Pads

Brake rotors of disc brakes rotate with the wheels, and brake pads, which are fitted to the brake calipers, clamp on these rotors to stop or decelerate the wheels. The brake pads pushing against the rotors generate friction, which transforms kinetic energy into a thermal energy.
This thermal energy generates heat, but since the main components are exposed to the atmosphere, this heat can be diffused efficiently. This heat-dissipating property reduces brake fade, which is the phenomenon where braking performance is influenced by the heat. Another advantage of disc brakes is its resistance to water fade, which occurs when the water on the brakes significantly reduces braking force. When the vehicle is in motion, the rotor spins at high speeds and this rotational motion discharges the water from the rotors themselves, resulting in stable braking force.
Disc brakes are generally used in passenger cars, but due to their stable performance at higher speeds and resistance to brake fade, they are gradually spreading into the commercial vehicle segment, where drum brakes were traditionally chosen for their longer service life. There is increasing demand from customers for longer service life and higher quality, and Baiyun is committed to meeting them through further development of the disc brake’s reliability. There are two types of disc brakes.
The "opposed piston type disc brake" has pistons on both sides of the disc rotor, while the "floating type disc brake" has a piston on only one side. Floating caliper type disc brakes are also called sliding pin type disc brakes.

The feature of BAIYUN car brake pads

The data of BAIYUN car brake pads

Advantage of Baiyun Brakes
1). Excellent formula. Various formulas are suitable for different models and road conditions
2). Equipped with commercial vehicle bench test bench and passenger vehicle bench test bench, 1:1 simulated real brake friction performance test, each formula and product for strict testing.
3). Automatic large scale batching system with accurate matching.Ensure uniform quality of ingredients.
4), the equal ratio press presses, presses the finished product density unification, the quality is consistent.
5), automatic unmanned operation press, automatic packing and steel back, automatic flattening, automatic pressing, eliminate the error rate of manual operation, to ensure the quality of finished products.

Brakes Production process

1). Production process of drum brake linings for commercial vehicles:
Stir ingredients -- -- -- -- -- - > pressure molding (pressing blank + pressure molding) -- -- -- -- -- -- -- -- -- -- -- - > > heat treatment chamfering, grinding inside arc -- -- -- -- -- - > -- -- -- -- -- - > drilling grinding outer arc rubbing surface -- -- -- -- -- - > brush ash printed label -- -- -- -- -- - > thermoplastic packing -- -- -- -- -- - > artificial packing packaging
2). Production process of disc brake pads for passanger cars:
Ingredients stirring + polishing of the steel back -- -- -- -- -- - > glue -- -- -- -- -- - > pressure molding - -- -- -- -- -- -- -- -- -- -- - > > heat treatment friction surface grinding, chamfering, slot -- -- -- -- -- - > spray painting -- -- -- -- -- - > the silencing pills -- -- -- -- -- - > surface coated -- -- -- -- -- > spring, three jaw -- -- -- -- -- - > thermoplastic packing -- -- -- -- -- - > artificial packing packaging
3). Production process of disc brake pads for commercial vehicles:
Ingredients stirring + polishing of the steel back -- -- -- -- -- - > glue -- -- -- -- -- - > pressure molding - -- -- -- -- -- -- -- -- -- -- - > > heat treatment friction surface grinding, chamfering, slot -- -- -- -- -- - > spray painting -- -- -- -- -- - > laser marking loading -- -- -- -- -- - > spring -- -- -- -- -- - > thermoplastic packing -- -- -- -- -- - > artificial packing packaging
