High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
Specifications
Brand Name :
CHIYAN
Model Number :
CHIYAN-H1
Certification :
RoHs/REACH/Sb/Halogen free
Place of Origin :
China
MOQ :
10,000㎡
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2 Million ㎡ per month
Delivery Time :
15-30 days
Packaging Details :
Carton/Pallet
Density :
2.47
Refractive Index :
1.51
Young's Modulus :
75.6
Transmittance :
≥92
Volume Resistivity :
9.1
Dielectric Constant :
8.2
Softening Point :
830
Strain Point :
558
Annealing Point :
606
Thermal Conductivity :
98
Thermal Expansivity :
98
Photoelastic Coefficient :
27.2
Poisson's Coefficient :
0.23
Vickers-hardness :
700
Description

High Alumino Silicate Glass with High Transmittance for high-end smartphone tablet pc cover glass

High Alumino-Silicate Glass (CHIYAN-H1) is an eco-friendly high aluminosilicate ultra-thin glass, which increases the Al₂O₃ content in the composition to improve the ion exchange efficiency, so that it has excellent mechanical properties after chemical strengthening.

Features:

High Impact Resistance

High Scratch Resistance

High Transmittance

High chemical resistance

High Flexibility

High Bending Strength Resistance

Ultra Clear White

Application: Widely used in high-end consumer electronics device cover, vehicle display, industrial touch panels, smart home screen display etc fields;

Regular Thickness:

0.3mm~6mm

CHIYAN-H1’s 0.3~6.0mm thickness high alumino-silicate glass has already been used in the market to meet a wide range of customers needs.

Standard Size:1300*1100mm (5th Generation)

Note: The size can be customized according to customer's needs.

Product Composition

High Alumino-Silicate Glass achieves better stress and strain depth than ordinary soda-lime glass by increasing the Al₂O₃ content in the glass and increasing the ion exchange capacity.

Chemical Tempering Process Parameter

CS >900Mpa
DOL >50um
4PB >800Mpa

Note: Tempering solution Na+<0.5%. The above test results are affected by processing conditions, the data is for reference only, not as a basis for production.

Packaging Diagram

High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass

Storage
Storage conditions: Temperature ≤30℃, humidity ≤65% (no condensation), shelf life is 6 months from the date of delivery.

High Alumino-Silicate Glass(CHIYAN-H1) is adopted Float Glass Process.

Float glass is made by heating raw materials—silica sand, limestone, soda ash, and magnesium in a furnace. When melted, it’s then spread out over a sizable bed of molten tin. As it moves along rollers in the annealing oven during a controlled cooling process, this mixture slowly solidifies over the molten tin. From this point, a single, continuous smooth ribbon of glass emerges as below picture showed:

High Transmittance Alumino Silicate Glass For Smartphone Tablet Pc Cover Glass
