3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit
Specifications
Brand Name :
RGH
Model Number :
RTP35QV011A
Place of Origin :
Shenzhern,China
MOQ :
3PCS
Price :
Negotiable
Certification :
ISO9001/ISO14001
Payment Terms :
L/C, T/T,Paypal
Supply Ability :
3.5kk
Delivery Time :
3-5weeks
Packaging Details :
Standard Exportation Package
Size :
3.5 inches
Resolution :
240*320
Model :
TFT LCD Display
Viewing Angle :
12:00 o'clock
Interface :
RGB 18bit
Backlight Type :
LED
Brightness :
450 cd/m²
Panel Type :
IPS
Description

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

NO. Symbol Level Function
1 DE Data enable signal for RGB interface operation
2-4 GND Ground.
5 NC NC
6-11 R0-R5 data bus
12-17 G0-G5 data bus
18-23 B0-B5 data bus
24 SCL Serial clock input for SPl interface.
25 SDA Serial data inputloutput bidirectional pin for SPI Interface.
26 CS chip select signal
27 DCLK Dot clock signal for RGB interface operation
28 RESET Reset pin
29 HS Line synchronizing signal for RGB interface operation
30 VS Frame synchronizing signal for RGB interface operation
31 VCC Power Supply (Analog)
32 IOvCC Power Supply (Logic)
33 GND Ground.
34 LEDA Back Light Power Supply Anode(+)
35 LEDK Back Light Power Supply Cathode(-)
36 GND Ground.
37 XR Touch Panel XR
38 YD Touch Panel YD
39 XL Touch Panel XL
40 TU Touch Panel YU

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

3.5 Inch Touch Display 240x320 TFT IPS LCD Touchscreen HD Module RGB 18bit

FAQ

1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).

3. Do you support custom logo on the LCM?

A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.

4. How can I place a sample order?

A: Pls send us your inquiry, our sales will contact you soon.

5. What size LCD display can you provide?

A: 0.96 inch to 21.5 inch TFT LCD display we can provide.

7. What's your MOQ?

A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.

8. What shipping ways do you support?

A: We can consult with it.
