Specifications
Brand Name :
RGH
Model Number :
RT50HD020A
Certification :
ISO9001/ISO14001
Place of Origin :
Shenzhen,China
MOQ :
3PICS
Price :
Negotiable
Payment Terms :
L/C, T/T,Paypal
Supply Ability :
3.5kk
Delivery Time :
3-5weeks
Packaging Details :
Standard Exportation Package
Screen Size :
5.0 inch
Resolution :
720（RGB）X 1280
Response Time :
30ms
Interface :
MIPI
Viewing Angle :
ALL o’clock
Dimensions :
66.90 (H) X120.00(V) X1.90(T) mm
Brightness :
260 cd/m²
Contrast Ratio :
800:1
Viewing area :
63.10(H) X111.40(V)
Active area :
62.10(H) X110.40 (V)
Operating temperature :
-20℃~70℃
Storage temperature :
-30℃~80℃
Driving IC :
ILI9881C
Weight :
TBD
Number of Dots :
720（RGB）X 1280
Voltage for logic :
2.5V-6.0V
Display Type :
Thin Film Transistor (TFT) LCD
Backlight Type :
LED
Description

5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots

NO. Symbol Level Function
1 GND Ground
2 VCC Power setting
3 IOVCC Power setting
4 GND Ground
5 RESET TP-VDD
6 TE TE-PIN
7 LEDA LED power anode
8 LEDK LED power cathode
9 GND Ground
10 D3N MIPI DSI differential data pair.
11 D3P MIPI DSI differential data pair.
12 GND Ground
13 D2N MIPI DSI differential data pair.
14 D2P MIPI DSI differential data pair.
15 GND Ground
16 CLKN MIPI DSI differential clock pair.
17 CLKP MIPI DSI differential clock pair.
18 GND Ground
19 D1N MIPI DSI differential data pair.
20 D1P MIPI DSI differential data pair.
21 GND Ground
22 D0N MIPI DSI differential data pair.
23 D0P MIPI DSI differential data pair.
24 GND Ground

5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots 5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots

5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots5.0 Inch TFT Module IPS Lcd Display 720*1280 High-Definition LCD Screen For Medical Industrial Robots

FAQ

1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).

3. Do you support custom logo on the LCM?

A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.

4. How can I place a sample order?

A: Pls send us your inquiry, our sales will contact you soon.

5. What size LCD display can you provide?

A: 0.96 inch to 21.5 inch TFT LCD display we can provide.

7. What's your MOQ?

A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.

8. What shipping ways do you support?

A: We can consult with it.
