Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom
Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom
Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom
Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom
Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom
Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom
Specifications
Brand Name :
RGH
Model Number :
RT43WV001A
Place of Origin :
Shenzhern,China
MOQ :
3PCS
Price :
Negotiable
Certification :
ISO9001/ISO14001
Payment Terms :
L/C, T/T,Paypal
Supply Ability :
3.5kk
Delivery Time :
3-5weeks
Packaging Details :
Standard Exportation Package
Screen Size :
4.3 inch
Resolution :
800*480
Brightness :
420 cd/m²
Interface :
RGB
Viewing Angle :
ALL O'CLOCK
Dimensions :
105.40(W)*67.10(H)*3.05(T)
Backlight Type :
LED
Display Type :
IPS
Description

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 CustomIndustrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

Item Specification

Size

4.3 inch

Display mode

Transmissive TFT

Part NO.
RT43WV001A

Resolution

 800*480

Outline size

105.40 (W) X67.10(H) X3.05(T)

Active area
95.04(W) X53.86 (H)

View direction

ALL o’clock

Piexl pitch
800X(RGB)X480

Interface

 RGB

Backlight

 7LEDS

Surface luminance

 420cd/m2

Logic voltage

2.5V-3.3V

Operating temperature
-20℃~70℃

Storage temperature
-30℃~80℃

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

NO Symbol Level Function
1 LEDK LED,cathode.
2 LEDA LED.anode
3 GND VSs Ground.
4 VCC 2.8V(typ Power supply.
5-12 R0-R7 H/L Data Bus.Serial 8-bitdata input selection.
13-20 G0-G7 H/L Data Bus.Serial 8-bit data input selection.
21-28 B0-B7 H/L Data Bus.Serial 8-bit data input selection.
29 GND VSs Ground.
30 CLK Sample clock.
31 DISP Display Mode.
32 HSYNC Horizontal synchronizing signal.
33 VSYNC Vertical synchronizing signal.
34 DEN Data Enable.
35 NC No Connection.
36 GND VSs Ground.
37 XR(NC) Touch panel interface/NC
38 YD(NC) Touch panel interface/NC
39 XL(NC) Touch panelinterface/NC
40 YU(NC) Touch panel interface/NC

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

Industrial Digital IPS TFT LCD Display 4.3 Inch HD Resolution 800x480 Custom

FAQ

1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).

3. Do you support custom logo on the LCM?

A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.

4. How can I place a sample order?

A: Pls send us your inquiry, our sales will contact you soon.

5. What size LCD display can you provide?

A: 0.96 inch to 21.5 inch TFT LCD display we can provide.

7. What's your MOQ?

A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.

8. What shipping ways do you support?

A: We can consult with it.
