58VDC Ceramic Automotive Fuses , 100A Electric Vehicle Fuses Low Voltage
58VDC Ceramic Automotive Fuses , 100A Electric Vehicle Fuses Low Voltage
Specifications
Brand Name :
Dissmann
Model Number :
DNQ-A/X/H
Certification :
UL
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
L/C/TT
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material :
Ceramic
Color :
White
Rated Current :
5A-200A
Rated Voltage :
32VDC/58VDC/80VDC
Breaking Capacity :
DC1500A
Category :
aR
Keyword :
Electric Vehicle fuse
Application :
short-circuit protection fuses of pure electric vehicles and hybrid electric vehicles
Description

58VDC ceramic automotive fuses supplier in China

Product details of the 58VDC ceramic automotive fuses

This 58VDC ceramic automotive fuses is our DNQ series flat type fuses,the DNQ series are suitable line in circuit of 32VDC/58VDC/80VDC,rated current range of 5A-200A,breaking capacity up to DC1500A.The dimension and performance conform to UL248-20,ISO8820,JASO-D622,RoHS compliant and the installation available in M6 bolt.

Product type of the DNQ series fuses

Model

Rated current

Rated voltage

Breaking Capacity
DNQ-A 5A～200A 32Vdc 1.5KA
DNQ-X 5A～200A 58Vdc 1.5KA
DNQ-H 5A～200A 80Vdc 1.5KA
DNM-A 5A～200A 32Vdc 1.5KA
DNM-X 5A～200A 58Vdc 1.5KA
DNM-H 5A～200A 80Vdc 1.5KA

Dimension of the DNQ series fuse

58VDC Ceramic Automotive Fuses , 100A Electric Vehicle Fuses Low Voltage

Performance test requirements of the DNQ series fuse

Current testing

(A)

minimum time

(s)

Max time

(s)
75% 360000 -
200% 0 300
600% 0 1

Material of the DNQ series fuse

Component name

Material

Contact the foot

Kirsite

Copper alloy

Noumenon

Ceramics
