MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System
MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System
MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System
MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System
Specifications
Brand Name :
Dissmann
Model Number :
DNQ-H 80VDC 50A
Certification :
DIN43560/1
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000000pcs
Delivery Time :
5-8 days
Packaging Details :
Standard Carton Packing
Rated voltage :
80VDC
Rated current :
50A
Protection type :
aR
Breaking capacity :
1.5KA
Installation :
Install Bolt M5,Recommend Torque: 2.5N.m
UL Certification No. :
E496054
Description

Dissmann Bolt-down Fuse 80VDC 50A MINI Size Flat Type Fuse for Li-ion Battery System

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

PRODUCT DRAWING

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

Performance test requirements:

Current testing item Min time(s) Max time(s)
100% 360000 ∞
200% 0 300
500% 0 1

TEMPERATURE ASSESSMENT GRAPH:

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

TIME CURRENT CHARACTERISTIC DIAGRAM:

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

MANUFACTURING METEARIAL:

Part Material
Fuse wire Copper or Silver
End cap Zinc alloy or copper alloy
Fuse leg Zinc alloy or copper alloy
Fuse body Ceramic Tube
Filler Quartz sand

Storage temperature:

  • Product storage temperature:-40°C~105°C.
  • The relative humidity is not more than 70% at 40 ° C;
  • The relative humidity at 30 ° C is not more than 80%;
  • Under 20 ° C, the relative humidity is not more than 90%.
  • Packaging storage temperature:-40°C~70°C.
  • The relative humidity is not more than 40% at 40 ° C;
  • The relative humidity is not more than 50% at 30 ° C;
  • Under 20 ° C, the relative humidity is not more than 90%, and there is no condensation.
