Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted
Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted
Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted
Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted
Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted
Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted
Specifications
Brand Name :
Dissmann
Model Number :
EV-A-Q
Certification :
UL,CCC
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material :
Ceramic
Colour :
White
Usage :
Automotive EV Battery，Charging Module
Rated Voltage :
250VDC
Current Rating :
300A
Keyword :
Ceramic Automotive Fuse
Standard :
UL248-20、GB13539、IEC60269、GB31465
Breaking Capacity :
DC20KA
Description

Dissmann Fuse with more than 20 year's Automotive ceramic EV battery fuse

Product basic information:

1.EV-A-Q series fuse,dimension and performance conform:UL248-20,GB13539,IEC60269,GB3146

2.Rated Voltage: 250VDC

3.Rated Current:300/400A

4.Breaking Capacity:DC20kA

5.Compliance with EU and China RoHS directive

6.Compliance with the standard of UL248-20,GB13539,IEC60269,GB31456

Ceramic Fuse Product characteristic:

Model Rated current Power consumption Size code Installation
EV-A-Q-300 300 26.2 VJ1

Install Bolt M8,

Recommend Torque: 11N.m
EV-A-Q-400 400 39.4 VJ1

Automotive EV battery fuse Product materials:

Part Material
Fuse wire Copper or Silver
End cap Copper alloy tin plating
Fuse leg Copper alloy tin plating
Fuse body Ceramic Tube
Filler Quartz sand
Product dimension:
Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted

Current Temperature Characteristic Curve:

Automotive Ev Battery Ceramic Car Fuses 250vdc 300a Dc 20ka Bolted

Product type:

Number Model Product code Rated current I²t(A²Sec) Power consumption
1 CP/CT HBD-6CP/HBD-6CT 6 2 13 1.9
HBD-10CP/HBD-10CT 10 7.1 47.2 2.9
HBD-12CP/HBD-12CT 12 10.2 65.9 2.9
HBD-16CP/HBD-16CT 16 16.3 107.8 6.8
HBD-20CP/HBD-20CT 20 32.4 215.6 6.8
2 EP/ET HBD-16EP/HBD-16ET 16 25.6 130.5 3
HBD-20EP/HBD-20ET 20 40 225 3.5
HBD-25EP/HBD-25ET 25 25.3 255 6.8
HBD-32EP/HBD-32ET 32 31.7 346.5 11
HBD-35EP/HBD-35ET 35 51.5 495 11
HBD-40EP/HBD-40ET 40 104 903 8.9
HBD-45EP/HBD-45ET 45 106.5 1110 10
HBD-50EP/HBD-50ET 50 118.5 1290 11
HBD-56EP/HBD-56ET 56 137 1530 13.7
HBD-63EP/HBD-63ET 63 168 1978 15.6
HBD-80EP/HBD-80ET 80 353 3890 18
HBD-100EP/HBD-100ET 100 1200 4350 17
3 HP/HT HBD-32HP/HBD-32HT 32 108 13000 10.5
HBD-40HP/HBD-40HT 40 165 2100 13
HBD-50HP/HBD-50HT 50 260 3350 16
HBD-63HP/HBD-63HT 63 480 6000 19
HBD-80HP/HBD-80HT 80 900 11200 22.8
HBD-100HP/HBD-100HT 100 1460 18500 28
HBD-125HP/HBD-125HT 125 2400 30200 34.5
HBD-160HP/HBD-160HT 160 4300 54000 37.5
HBD-200HP/HBD-200HT 200 8100 101000 40
4 EEP/EET HBD-90EEP/HBD-90EET 90 492 4510 19
HBD-110EEP/HBD-110EET 110 605 6565 26.5
HBD-140EEP/HBD-140EET 140 1060 11880 34
HBD-160EEP/HBD-160EET 160 1470 16490 38.2
5 SM/ST HBD-180SM/HBD-180ST 180 1358 13230 39
HBD-200SM/HBD-200ST 200 2548 17760 40
HBD-225SM/HBD-225ST 225 3552 25200 42.8
HBD-250SM/HBD-250ST 250 4990 3560 47.5
HBD-280SM/HBD-280ST 280 6860 51000 48.2
HBD-315SM/HBD-315ST 315 9760 71600 54.5
HBD-350SM/HBD-350ST 350 14100 96600 55.6
HBD-400SM/HBD-400ST 400 18500 125000 58
6 SMM/STT HBD-400SMM/HBD-400STT 9680 69600 83.9
HBD-450SMM/HBD-450STT 450 14000 94800 90
HBD-500SMM/HBD-500STT 500 19200 136500 99.8
HBD-550SMM/HBD-550STT 550 27600 195650 100.3
HBD-630SMM/HBD-630STT 630 40800 272800 101.9
HBD-700SMM/HBD-700STT 700 54000 373800 119.2
