Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Specifications
Brand Name :
Dissmann
Model Number :
DKN-A
Certification :
UL
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material: :
electric wood shell
Colour: :
Red
Rated Voltage: :
32VDC
Rated Current: :
2A-30A
Breaking Capacity: :
DC1000A
Standard: :
UL248、ISO8820、ROHs
Usage: :
low voltage automotive
Keyword： :
low voltage automotive fuse
Description

Fast Blow Fuse Mini Cartridge Fuse Low Current Fuse Automotive Fuse

Material:
Noumenon: electric wood shell
Pins: Copper alloy

Features:

Automotive Cartridge Fuse
Many kinds of Automotive Cartridge Fuse
Current rating: 2A-30A
Voltage rating: 32VDC

Breaking capacity:DC1000A

Product Presentation:

Rated Voltage

32VDC

Characteristic

Fast
Rated Current 2A-30A

Breaking Capacity

DC1000A

Meet the Requirement

UL248,ISO8820,

EU and RoHS Directive

Remarks

UL


Overall dimensions of the product(mm)
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Current characteristic curve
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse

Product type

Model

Product code

Rated current

( A )

I²t

(A²Sec)

Voltage drop

( mV )

Pigment

DKN-ADKN-A-222.8170Gray
DKN-A-339.3152Violet
DKN-A-4417120Pink
DKN-A-5524128Tan
DKN-A-7.57.566135Brown
DKN-A-101092108Red
DKN-A-151527098Blue
DKN-A-202038096Yellow
DKN-A-252562085Clear
DKN-A-3030112086Green

Performance criteria

Test current item(A)CurrentMinimum time(s)Maximum time(s)
110%2A-30A360000∞
135%2A-30A0.75600
200%2A-30A0.155.0
350%2A-30A0.080.5
600%2A-30A0.030.1


Test Equipment
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
Production Equipment
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse

Our Certificates
Electric Wood Shell Low Current Fuse , UL248 2 Amp Fast Blow Fuse
