58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
Specifications
Brand Name :
Dissmann
Model Number :
DFN-X
Certification :
UL
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material: :
electric wood shell
Colour: :
Brown
Rated Voltage: :
58VDC
Rated Current: :
1A-40A
Breaking Capacity: :
DC1000A
Standard: :
UL248、ISO8820、ROHs
Usage: :
low voltage automotive
Keyword: :
low voltage automotive fuse
Description

Low Voltage Automotive Fuse Fast Blow Cartridge Fuse Low Current Fuse

Material:
Noumenon: electric wood shell
Pins: Copper alloy

Product Presentation:

Rated Voltage

58VDC

Characteristic

 Fast Blowing
Rated Current 1A-40A

Breaking Capacity

 DC1000A

Meet the Requirement

UL248,ISO8820,

EU and Rosh Directive

Remarks

 UL

Overall dimensions of the product(mm)

58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard

Product type

Model

Product code

Rated current

I²t

(A²Sec)

Voltage drop

Pigment
DFN-X DFN-X-1 1 0.4 174 (Black)
DFN-X-2 2 1.5 140 (Gray)
DFN-X-3 3 6.3 137 (Violet)
DFN-X-4 4 13 135 (Pink)
DFN-X-5 5 25 125 (Tan)
DFN-X-7.5 7.5 56 115 (Brown)
DFN-X-10 10 110 110 (Red)
DFN-X-15 15 295 102 (Blue)
DFN-X-20 20 480 96 (Yellow)
DFN-X-25 25 1000 90 (Clear)
DFN-X-30 30 1460 86 (Green)
DFN-X-35 35 2205 88 (Dark green)
DFN-X-40 40 3200 95 (Orange)

Currentcharacteristiccurve

58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard

Performance criteria

Test current item(A) Current Minimum time(s) Maximum time(s)
110% 1A-40A 3600 ∞
150% 1A-40A 0.5 300
200% 1A-40A 0.15 20
350% 1A-40A 0.04 0.5
600% 1A-40A 0.02 0.1

Test equipment

58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
Production equipment
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
Our Certificates
58V DC Low Voltage Fuses 1 Amp Rated Current: Fast Blow ROHs Standard
