White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard
Specifications
Brand Name :
Dissmann
Model Number :
EV-H-Q
Certification :
UL
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material :
Ceramic
Colour :
White
Rated Voltage :
AC/DC500V
Rated Current :
250A
Breaking Capacity :
DC20KA/AC100KA
Standard :
UL248-20、ISO8820、 JASO-D622、ROHS
Usage :
solar,automotive,charging pile
Keyword :
Solar fuse
Description

High Current Ev Fuse 250amp Fuse High Braking Capacity Fuse Charging Pile Fuse

Material:
Noumenon: Ceramic
Pins: Copper alloy

Product Presentation

Rated Voltage

AC/DC500V

Type Protection

 aR
Rated Current 10A-500A

Breaking Capacity

 AC100KA,DC20KA

Meet the Requirement

UL248-20,ISO8820,JASO-D622,

Europe and RoHS directive

Remarks

UL

Overall dimensions of the product(mm)

White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard

Model Dimension code A±2 B±1.5 C±1 D±1.5 F±1 G±0.5 H±0.2 J±1
EV-H-Q VH1 94.5 30.5 52.5 74.5 9 25 4 13
VH2 119.5 37 56.5 88.5 11 25 6 15

Current characteristic curve

White 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 StandardWhite 250 Amp Automotive Fuse , Electric Car Fuse UL248-20 Standard

Product type

Model

Rated current

(A)

 I²t(A²s)

Power consumption

(W)

Size Code

Install
Pre-Arc After-Arc
EV-H-Q-80 80 5500 6400 15 VH1

Mounting Bolt M8 recommended torque 11N·m
EV-H-Q-100 100 8700 10000 19
EV-H-Q-125 125 15000 17810 23.5
EV-H-Q-150 150 25000 29000 28
EV-H-Q-175 175 40500 45000 33
EV-H-Q-200 200 60300 68000 37
EV-H-Q-225 225 83100 95000 40
EV-H-Q-250 250 120000 138000 45
EV-H-Q-275 275 173200 189000 48
EV-H-Q-300 300 203000 243000 55.5
EV-H-Q-350 350 252000 355000 62
EV-H-Q-300 300 148500 260000 53.5 VH2

Mounting Bolt M10 recommended torque 20N·m
EV-H-Q-315 315 168000 280000 57
EV-H-Q-350 350 203000 350000 61
EV-H-Q-400 400 312000 496000 68
EV-H-Q-500 500 550000 865000 78
