White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
Specifications
Brand Name :
Dissmann
Model Number :
10*38
Certification :
UL,CCC,TUV
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material: :
fiber pipe
Colour: :
White
Rated Voltage: :
1000VDC
Rated current: :
1A-100A
Usage: :
high voltage automotive,PV,Power bank
Keyword: :
Energy storage fuse
Description

Power bank fuse high volt fuse 10*38 fuse PV fuse Charging pile fuse

Material:
Noumenon: fiber pipe
Pins: Alloy

Product Presentation:

Rated Voltage

额定电压

 80VDC-1000VDC

Characteristic

特性

 aR
Rated Current 额定电流 20A-100A

Breaking Capacity

分断能力

Meet the Requirement

符合要求

UL248,IEC60127,

欧盟和RoHS 指令

Remarks

备注

 UL,TUV

工程图及材料表 / Drawing and material sheet

White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC

Assembly组件 Material quality 材质
Fusant熔体 Alloy合金
End cap端帽

Copper alloy tin plating

铜合金镀锡
Noumenon本体 Fibre pipe 纤维管
Infilling填充物 Quartz sand 石英砂

产品型号/Product type

Model型号

Rated current

额定电流A

Rated voltage

额定电压V

Breaking capacity

分断能力
HDQ10PV 25A～30A 1000Vdc 10KA
HDQ10P 25A～30A 750Vac/dc
HDQ10D 25A～40A 500Vdc
HDQ10MN 25A～40A 690Vac/dc
HDQ10N 25A～40A 690Vac
HDQ10M 25A～40A 690Vdc
HDQ10X 30A～100A 500Vac 1.5KA
HDQ10C 30A～100A 400Vdc
HLQ10L1 30A～100A 200Vdc
HLQ10L2 30A～100A 100Vdc
HLQ10L 30A～100A 80Vdc
Test equipment
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
Production equipment
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
White Fuse 10 X 38 For Power Bank 100 Amp Rated Current 1000VDC
