Specifications
Brand Name :
Dissmann
Model Number :
MEV-P-DXX
Certification :
UL,CCC,TUV
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material: :
fiber pipe
Colour: :
White
Rated Voltage: :
750VDC
Rating current: :
250A
Usage: :
Charging pile,PDU,Automobile
Keyword: :
Industrial power fuse
Description

low current fuse Automotive with indicator fuse energy storage fuse

Material:
Noumenon: fiber pipe
Pins: Alloy

Product Presentation:

Rated Voltage

额定电压

DC750V,AC690V

或低于

Type Protection

保护类别

 aR
Rated Current 额定电流 250A-500A

Breaking Capacity

分断能力

DC10KA

(时间常数≤10ms)

Meet the Requirement

符合要求

UL248-20,ISO8820,JASO-D622,

欧盟和RoHS 指令

Remarks

备注

 UL

产品外形尺寸(mm)/Overall dimensions of the product(mm)

Energy Storage Car Fuse With Indicator Light 250A Rating Current Fiber Pipe

产品型号/Product type

Model

型号

Product code

产品代码

Rated current

额定电流 A

 I²t(A²Sec)

Power consumption

功率损耗 W
弧前 总
MEV-P-D20 MEV-P-D20-250 250 6250 42000 45
MEV-P-D20-315 315 10000 68500 55
MEV-P-D30 MEV-P-D30-250 250 6250 42000 45
MEV-P-D30-315 315 10000 68500 55

电流特性曲线图/Current characteristic curve MEV-P-D20(10A～200A)/ MEV-P-D30(10A～200A)

Energy Storage Car Fuse With Indicator Light 250A Rating Current Fiber Pipe

TUV certificate:

Energy Storage Car Fuse With Indicator Light 250A Rating Current Fiber Pipe

Energy Storage Car Fuse With Indicator Light 250A Rating Current Fiber Pipe

Tag:Industrial fuse,Dissmann MEV fuse,European square fuse,Energy storage fuse,Automotive fuse,european square fuse mev-500v semiconductor protection fuse, China, manufacturers, suppliers, factory, BS88 Fuses Equivalent To Bussmann Fuse, Schematic Diagram Of Fuse-link Current Limiting Characteristic Waveform, North American Fuse 5A To 800 A, fuse clips types, Fuse With Certificates UL and TUV, Fuses of Automotive Passenger Car
