315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
Specifications
Brand Name :
Dissmann
Model Number :
MEV-H-F00
Certification :
UL、TUV
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material :
Ceramic
Colour :
White
Usage :
Energy Storage system,PV,inverter
Rated Voltage :
500VDC
Rated Current :
315A
Keyword :
Energy Storage Systems Fuse
Standard :
UL248-13、ISO8820、 JASO-D622、IEC60269、ROHS
Breaking Capacity :
DC20KA
Description

315 Amp Energy Storage Systems Fuse

1,Product Details:

Rated Voltage: DC500V or lower

Rated Current:315A/450A/630A;

Class of Protection:aR;

Breaking Capacity:DC20kA(time constant≤10ms)

Compliance with EU and China RoHS directives

Compliance with the requirements of QC/T413,ISO8820,JASOD622

2,315 Amp Fuse Product Material:

Part Material
Fuse wire Copper or Silver
End cap Copper alloy tin plating
Fuse leg Copper alloy tin plating
Fuse body Ceramic Tube
Filler Quartz sand

3,315 Amp High Speed Fuse Characteristic data

Model Rated Current Installation
MEV-H-F00-315 315A

Mounting bolt M8 recommended torque 11N.m
MEV-H-F00-450 450A
MEV-H-F00-630 630A

4,Product Dimensions(mm)

315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square

5,Conditions of use

Normal use conditions and parameter correction

The fuses work normally under the following normal conditions and no any additional correction required.

When it exceeds the normal using conditions, some parameters or consultation may need to be corrected if they are within the allowable using conditions. If it is beyond the scope of allowable using conditions, you should consult our company, and carry out the work adaptability evaluation and test of the conditions.

It is recommended that the current value of long-term current shall not be greater than 80% of the rated current.

Product equipment:
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square

Test equipment:
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square

Certificate:
315 Amp High Speed 500VAC ESS Fuse 51x51mm European Square
