Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water
Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water
Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water
Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water
Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water
Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water
Specifications
Brand Name :
Desun Uniwill
Model Number :
DS305
Certification :
CE
Place of Origin :
China
MOQ :
0-100PCS
Price :
According to the specific quantity
Payment Terms :
T/T, L/C, D/A, D/P
Delivery Time :
7-15 working days
Packaging Details :
carton packaging
Product name :
Blue Green algae sensor
Principle :
Fluorescence method
Measure range :
0-270, 000 cells/mL
Resolution :
1 cells/mL
Detection limit :
300 cells/mL
Housing material :
SS316
Power supply :
5~12vdc,current <50mA (when not cleaned)
Output Signal :
RS485, MODBUS protocol
IP grade :
IP68
Deepest depth :
Underwater 10 meters
Description

Desun Uniwill Online RS485 Blue Green Algae Sensor system for water

Introduction

The online blue-green algae sensor uses the principle of fluorescence method, which is more efficient and faster than the traditional manual counting method and can be monitored in real-time online. The sensor has better repeatability and stability. With an automatic cleaning brush, it can eliminate air bubbles and reduce the impact of contamination on the measurement, make the maintenance cycle longer, and maintain excellent stability for long-term online use It can play an early warning role on algae reproduction. A blue-green algae sensor is a specialized device used for the detection and monitoring of harmful algal blooms (HABs) caused by cyanobacteria. These sensors are designed to measure specific parameters related to blue-green algae, such as chlorophyll-a, phycocyanin, and phycobiliprotein fluorescence.

Features

★ Digital sensor, RS-485 output, support MODBUS
★ With automatic cleaning brush to prevent contamination and eliminate air bubbles
★ Direct measurement, simpler than the traditional manual counting method
★ Continuous online monitoring, real-time control of water quality dynamics

Technical parameter

Product name Blue-green Algae Sensor
model DS305
principle Fluorescence method
Range 0-270, 000 cells/mL
Detection limit 300 cells/mL
Resolution 1 cells/mL
Linearity R2>0.99
temperature range 0~ 50°C
Protection level Ip68
Sensor interface Support RS-485, MODBUS protocol
Installation Input type,
Power information DC 5~12V, current <50mA
size Φ45*175.8mm
Probe cable length 10 meters (default), can be customized
Housing material SS316
Self-cleaning system Have













Desun Uniwill Online RS485 Blue Green Algae Sensor System For Water

Applications of blue-green algae sensors:

Environmental Monitoring:
Blue-green algae sensors are used for monitoring and tracking the presence and dynamics of blue-green algae in natural bodies of water, including lakes, rivers, and coastal areas. This helps in assessing the overall water quality and identifying potential HABs.

Drinking Water Source Protection:
Blue-green algae sensors can be deployed in reservoirs and water supply sources to monitor the levels of blue-green algae. Real-time data from these sensors can help water treatment plants to take appropriate measures to ensure safe and clean drinking water.

Recreational Water Safety:
Blue-green algae sensors are useful for monitoring the water quality in swimming areas, beaches, and recreational lakes. By identifying the presence of blue-green algae, timely warnings and advisories can be issued to protect swimmers and other recreational users from potential health risks.

Aquaculture Management:
Blue-green algae sensors play a critical role in managing aquaculture facilities, such as fish farms and shrimp ponds. By continuously monitoring blue-green algae levels, aquaculture operators can prevent or mitigate the potential damage caused by HABs to aquatic species and maintain optimal water quality conditions.

Ecological Research:
Blue-green algae sensors are valuable tools for researchers studying the ecology and dynamics of cyanobacteria blooms. The collected data helps in understanding the factors contributing to the formation and persistence of HABs and their impacts on ecosystems.
