Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Specifications
Brand Name :
Desun Uniwill
Model Number :
DS-380
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Price :
$280.00 - $400.00/ Piece
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
1000 sets per month
Delivery Time :
7~ 15 working days
Packaging Details :
Carton packaging
Model :
DS380
Principle :
Fluorescence analysis method
Measuring range :
0~20mg/L
Response time :
1-10 seconds
Accuracy :
1%
Protection level :
IP68
Installation :
Submersible
Temperature sensor :
0~50°C
Temperature accuracy :
±0.2°C
Output :
Support RS-485, MODBUS protocol
Power supply :
DC 6~12V, current <50mA
Size :
Φ26*155 mm
Probe cable length :
Default 5 m
Fluorescent cap life :
1 year
Maximum working pressure :
3bar
Housing material :
SS316/Titanium alloy
Description

Aquarium Analog Smart Optical Dissolved Oxygen Sensor Do Sensor For Water

Description

The fluorescent dissolved oxygen sensor is based on the quenching principle of the specific fluorescence of the particular substance in physics. Blue light from a light-emitting diode (LED) illuminates the fluorescent material on the inner surface of the fluorescent cap, and the fluorescent material on the inner surface is excited to emit red light by detecting the phase difference between red and blue light and the internal calibration value. The ratio is calculated to calculate the concentration of oxygen molecules, and the final value is automatically compensated by temperature and pressure.

Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Features
* 0-20mg/L or 0-200% saturation
* 0~50 °C; IP68 protection level
* No film, no electrolyte, no polarization
* No need to consume oxygen, no flow rate
* Built-in temperature sensor, automatic temperature compensation
* Free from chemical interferences such as sulfides
* Small annual drift, fast response, and more accurate measurement
* Free of maintenance, longer application cycle, and lower cost of use
* Fluor cap replacement is simple
*Support RS-485, MODBUS protocol
Aquarium Analog Smart Optical Dissolved Oxygen Sensor DO Sensor For Water
Technical parameters
Model
Fluorescent dissolved oxygen sensor
Measuring Range
0-20mg/L or 0 ≤ 200% saturation
Response time
5 s
Precision
± 5%
Sensor drift
<1% per year
Temperature range
0~50℃
Temperature precision
± 0.5℃
Calibration method
One or Two-point calibration
output method
RS-485 (Modbus/ RTU )
Temperature sensor
NTC
Housing diameter
22mm
Housing length
188.3
Cable length
5 m, in addition to the customer, 5 m, 15 m and 30 m cables.
Power consumption
< 0.5 W
power supply
DC6~12v +/-5%, current<50mA
Protection level
IP68
Housing Material
SS316/Titanium
