Overload Protection 50HZ UPS Power Supply Backup 120~295V With Monitoring Software
Overload Protection 50HZ UPS Power Supply Backup 120~295V With Monitoring Software
Overload Protection 50HZ UPS Power Supply Backup 120~295V With Monitoring Software
Overload Protection 50HZ UPS Power Supply Backup 120~295V With Monitoring Software
Specifications
Brand Name :
Baikong
Model Number :
UPS
Certification :
ISO9001,3C
Place of Origin :
Sichuan,China
MOQ :
1sets
Price :
$1000-$100000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 Piece/Pieces per week
Delivery Time :
To be negotiated
Packaging Details :
Factory high quality packing carton or wooden case
product name :
UPS power supply room monitoring UPS uninterruptible power supply
Size :
customized
Material :
customized
Protect :
Overload, Short circuit, Voltage Stabilization
Application :
Large Computer Rooms / Hospitals / Military
power :
1000/700
frequency :
50±0.2%(Battery mode)
voltage range :
120~295
Voltage :
220±2%
Description

UPS power supply room monitoring UPS uninterruptible power supply

Overview

A new generation of high-reliability and high-performance sine wave online power supply products using the same independent patent technology. It has the characteristics of full-featured, small size, high efficiency, simple operation, etc., especially suitable for harsh power grid environment.

The main technical parameters

index model KR1000 KR1000L KR2000 KR2000L KR3000 KR3000L KR6000 KR6000L KR1110S KR1110
lose
enter
special
sex		 voltage range 120~295 120~275
Frequency Range(Hz) 50±10%
Phase Single-phase three-wire
Power factor At full load ≥0.98
battery voltage(VDC) 36 72 96 192
lose
out
special
sex		 power(VAW) 1000/700 2000/1400 3000/2100 6000/4800 10000/8000
Voltage(V) 220±2%
frequency(Hz) 50±0.2%(Battery mode)
Wave Sine wave, THD≤3% (linear load)
Switching time(ms) 0
Overload capacity 105%~129% full load for 60 seconds; 130%~150% for 30 seconds; more than 150% for 300 milliseconds 105%~129% for 10 minutes: 130%~150% for 1 point
Clock; >150% for 1 second and then bypass
output method Two national standard sockets and one American standard socket
seat		 Two national standard sockets + 1 American standard socket + terminal block Wiring block
That
it
special
sex		 DC start have
Standby time 5 minutes Can be arbitrarily configured 5 minutes Can be arbitrarily configured 5 minutes Can be arbitrarily configured 5 minutes Can be arbitrarily configured 5 minutes Can be arbitrarily configured
Communication function RS232 interface, support power monitoring software RS232, USB (optional), support power monitoring software
SNMP(Option) Network monitoring via SNMP adapter
Panel display LED displays the operating status of the UPS The LED displays the operating status of the UPS, and the LCD displays the operating parameters of the UPS
Audio noise(dB) <45 <65
Parallel function without And the model has
Alarm function Low battery, abnormal mains power, overload, UPS failure, over-temperature protection
Protective function Input overvoltage protection, battery undervoltage protection, overload protection, short circuit protection, over temperature protection
Operating temperature(℃) 0~40
Relative humidity 0~95%,No condensation
Dimensions (width x depth x height)
(mm)		 156x400x220 198x490x347 255x565
x700		 255x565
x500		 255x565
x700
255x565
x500
weight(kg) 13 6.5 25 14 29 15 69 23 70 24

Features

● High performance design

Fully digital control, higher control precision of the whole machine, strong real-time performance and high integration;

Advanced DSP+MCU control, the whole machine has a higher level of intelligence;

● Reliability design

Equipped with an output isolation transformer to prevent the impact of the output DC component on the load, reduce the output zero-ground voltage, meet the requirements of special industries for the zero-ground voltage, and enhance the impact resistance of the system output;

Online double conversion structure design, the protection equipment can work safely;

Super power input adaptability, strong grid adaptability;

Wide input voltage input frequency range, reduce battery discharge opportunities, and extend battery life;

The input has a lightning surge protection design, effective protection equipment under special conditions;

● Humanized design

Chinese/English LCD liquid crystal display, which can display UPS working status and parameter information in real time, which is convenient for users to check

UPS management;

Through the LCD, the working parameters can be flexibly set;

Real-time battery remaining capacity display, easy to observe battery working status;

Super network monitoring function, with RS232/RS485 output interface, easy to connect with the computer to realize the monitoring of UPS;

Remote SNMP monitoring and management function; providing real-time UPS information;

With DC start function, the UPS can be started normally when there is no mains power; at the same time, it has the automatic start of mains power to realize unattended operation;

● Perfect protection function

Overload protection, over temperature protection, short circuit protection, output over and under voltage protection, real-time protection function, to ensure the reliability of UPS and load equipment from damage;

Battery overcharge protection, overdischarge protection, reverse connection protection, etc., to ensure that the battery is not damaged and extend the battery life.
