5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
Specifications
Brand Name :
OEM
Model Number :
OKY3014
Place of Origin :
CHINA
MOQ :
10pcs
Price :
USD$2.64-3.30/pcs
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs/day
Delivery Time :
3-47working days
Packaging Details :
Different package at optional: 1. Retailing Package:Anti-static bag 2. Bulking Packing:Plastic Bag Package 3. Retailing Box package design according to your requirement( Order > 2000PCS)
Maximum load on normally open pin :
AC 250V/10A, DC 30V/10A
Trigger current :
5mA
Voltage :
5V/12V at optional, please tell which one you need when make order
The working voltage :
5V
Channel :
8 channel
IN1~IN8 :
relay signal triggering pin
Module size :
141.5mm * 50mm* 18.5mm
Weight :
120g
Description

HOT sale relay module 12v relay price, 5V / 9V/12V /24V 8 Channel Relay Module for Arduino

Descriptions:

Name Specification
Maximum load on normally open pin AC 250V/10A, DC 30V/10A
Trigger current 5mA
Voltage 5V/12V at optional, please tell which one you need when make order
The working voltage 5V
Channel 8 channel
DC+ DC power supply positive pole
DC- DC power supply negative pole
IN1~IN8 relay signal triggering pin
Normally closed pin (NC1~NC8) relay normally closed pin
Common pin (COM1~COM8) relay common pin
Normally opened pin (NO1~NO8)

relay normally opened pin

Available With:

This is a 5V 8-Channel Relay interface board, Be able to control various appliances, and other equipments with large current. It can be controlled directly by Microcontroller. Supports all MCU control.
The industrial field.
PLC control.
Smart home control.

Photos:

5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module5V / 9V / 12V / 24V 8 Channel Relay Module for Arduino , arduino relay module
