US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter
US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter
US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter
US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter
US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter
US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter
Specifications
Brand Name :
OEM
Model Number :
OKY3262
Place of Origin :
China
MOQ :
10
Price :
2.38~2.98/piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability :
1000pcs per week
Delivery Time :
3-5 work days
Packaging Details :
standard package
Working Voltage :
2.4V-5.5V
Working Temperation :
-20 to +70degrees
Static current :
Less than 2mA
Sensor angle :
Less than 15 degrees
Detection distance :
2cm-450cm
Detecting precision :
0.3cm+1%
Weight :
10g
Material :
Material
Size :
45*20*15 mm
Description

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Description:

Name Ultrasonic Sensor US-100 Distance Measuring Module with Temperature Compensation Range distance 10 meter
Working Voltage 2.4V-5.5V
Working Temperation -20 to +70degrees
Static current Less than 2mA
Sensor angle Less than 15 degrees
Detection distance 2cm-450cm
Detecting precision 0.3cm+1%
Weight 10g
Material PCB
Size 45*20*15 mm
Wiring Way VCC, trig (control terminals), echo (receiver), GND
Operation Guide A control mouth hair a 10 US above the high level, can wait for high level output receiver mouth. A has an output can open timer time, when the mouth into a low power can be read at ordinary times timer values, where you for the ranging time, can calculate the distance. This will continue the cycle, can reach you move measurement value
working Principle (1) the IO trigger ranging, to at least 10 us high level signal;
(2) automatically send eight 40 KHZ of square wave, automatic testing if it has any signals return;
(3) a signal to return to, through the IO output top level, the duration of the high level is from the launch ultrasonic returned to time. Test distance = (high level time * sound velocity (340 M/S)) / 2;

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Factory Picture:

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Our Team:

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Awards:

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Packing&Shipping:

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Shopping Ways and Time Needed:

US-100 Ultrasonic level Sensor With Temperature Compensation Range distance 10 meter

Competitive Advantages:

1. Convenient & Friendly Customer Service.

2. Low Prices Direct From Factory Suppliers.
3. Fast Delivery Around the World.
4. High Quality With Global Standards.
5. 1 Year Factory Warranty.
6. Safe Shipping Way and Payment.

Competitive Advantages:

1. Convenient & Friendly Customer Service.

2. Low Prices Direct From Factory Suppliers.
3. Fast Delivery Around the World.
4. High Quality With Global Standards.
5. 1 Year Factory Warranty.
6. Safe Shipping Way and Payment.
