Specifications
Brand Name :
DLON
Model Number :
DL360-24V
Certification :
CE, RoHS
Place of Origin :
Guangzhou China
MOQ :
50 pcs
Price :
$39 ~ $45
Supply Ability :
10000 pcs per month
Packaging Details :
box and carton, 12 pcs/ carton
Size :
180*90*63mm
Weight :
1.2kg
Input Voltage :
85VAC-250VAC
Max wattage :
360W
Ambient temperature :
-20 °C to +50°C
Protection :
SCP,OVP,OCP,OTP
Application range :
scooter,E-bicycle,E-motorcycle,tourism bus,floor washer,golf cart etc
Warranty :
18 months
Description

12v 36v 48v 60v lipoly charger 24v 60ah lifepo4 battery charger for motorbike battery lifepo4

Brief description :

1. Aluminium case , light weight

2. Input voltage ; AC 100 V ~240 V 50 / 60 HZ

3. Max wattage : 360 W

4. Charge mode : 3 stage ( CC CV float mode )

5. Charging : High saturation and efficiency

6. Input plug(power cords) : EU US UK AUS Italy Plugs etc ( can be Customized)

7. Output Connector : DC jack, XLR, JST, Cigar Lighter, Alligator Clips etc

The 3-stage mode charging :

First stage ( constant current ) : The charger will supply constant current for the battery

Second stage ( constant voltage ) : The voltage will be rising under the first stage, when it reach constant voltage value, it will turn into the second stage. The current will be slowly smaller until it reduce to floating value,the CV stage will end.

Third stage ( Floating charging ) : When the current is approaching the value of transition, the charger will cut down to the given current gradually, that means the battery power is full and indicator light turn to green. At this moment, the battery can be stopped charging or keep on trickle current charging for half an hour.

The 360w battery charger specification :

Nominal

Output Voltage		 CV CC Transition / Cut-off Current Net Weight Size
Lead Acid Li-ion LiFePO4 A Lead Acid (A) Li(A) (kg) (mm)
DL360W-12V 14.7V 16.8V 14.6V 20A 4.0 1.0 1.2 180*90*63
DL360W-24V 29.4V 29.4V 29.2V 12A 2.4 0.6
DL360W-36V 44.1V 42.0V 43.8V 8A 1.6 0.4
DL360W-48V 58.8V 54.6V 58.4V 6A 1.2 0.3
DL360W-60V 73.5V 67.2V 73.0V 5A 1.0 0.25
DL360W-72V 88.2V 84V 87.6V 4A 1.8 0.2


Note: Cut-off point for Li battery is 5% of CC, and it can be setted between 3-10%.

12v 36v 48v 60v lipoly charger 24v 60ah lifepo4 battery charger for motorbike battery lifepo412v 36v 48v 60v lipoly charger 24v 60ah lifepo4 battery charger for motorbike battery lifepo412v 36v 48v 60v lipoly charger 24v 60ah lifepo4 battery charger for motorbike battery lifepo412v 36v 48v 60v lipoly charger 24v 60ah lifepo4 battery charger for motorbike battery lifepo4

Package & Delivery

1. Package : one piece one neutral box , 12 pcs/ carton, can be customized

2. Delivery : 5 to 7 working days , big order according to actual quantity

3. Delivery port : Guangzhou port

4. Payment term : T/T or Western Union

5. Delivery way : by sea / by air / by express or as your requirement

12v 36v 48v 60v lipoly charger 24v 60ah lifepo4 battery charger for motorbike battery lifepo4
