Specifications
Brand Name :
DLON
Model Number :
DL120-12V
Certification :
CE, RoHS
Place of Origin :
Guangzhou China
MOQ :
50 pcs
Price :
$17.0 ~ $20.00
Supply Ability :
10000 pcs per month
Packaging Details :
box and carton, 12 pcs/ carton
Size :
135*90*50mm
Weight :
0.9 Kg
Input Voltage :
85VAC-250VAC
Max wattage :
120W
Ambient temperature :
-20 °C to +50°C
Use :
charging for lead acid battery
Protection :
SCP,OVP,OCP,OTP
Application range :
scooter,E-bicycle,E-motorcycle,tourism bus,floor washer,golf cart etc
Warranty :
18 months
Material :
Alumium alloy shell
Description

for electric bike using 12v battery charger for 12v 40ah lead acid batteries

Brief description :

1. Aluminium case , light weight

2. Input voltage ; DC 100 V ~240 V 50 / 60 HZ

3. Max wattage : 120 W

4. Charge mode : 3 stage ( CC CV float mode )

5. Charging : High saturation and efficiency

6. Input plug(power cords) : EU US UK AUS Italy Plugs etc ( can be Customized)

7. Output Connector : DC jack, XLR, JST, Cigar Lighter, Alligator Clips etc

The specification :

Nominal

Output Voltage

CV

CC

Transition / Cut-off Current

Net Weight

Size

Lead Acid

Li-MnO2

LiFePO4

A

Lead Acid (A)

Li(A)

(kg)

(mm)

DL120-12V

14.7V

16.8V

14.6V

6A

1.2

0.3

0.9

135*90*50

DL120-24V

29.4V

29.4V

29.2V

3A

0.8

0.2

DL120-36V

44.1V

42.0V

43.8V

2.5A

0.6

0.15

DL120-48V

58.8V

54.6V

58.4V

2A

0.4

0.10

Note: Cut-off point for Li battery is 5% of CC, and it can be setted between 3-10%.for electric bike using 12v battery charger for 12v 40ah lead acid batteries

for electric bike using 12v battery charger for 12v 40ah lead acid batteriesfor electric bike using 12v battery charger for 12v 40ah lead acid batteriesfor electric bike using 12v battery charger for 12v 40ah lead acid batteries

Charging Procedure :

1. First output power charger wire ends are connected to the battery anode and cathode , the charge

indicator turns green, the connection is correct, otherwise the charge in question, please check the

actual situation.

2. Then city power plug to socket , the indicator is red, charger will be into the charging state .

3. When the indicator light turns to green, the battery is charged to 95% , If you want to reach 100% ,

keep charging for 1 to 2 hours before end of charge.

4. When fully charged, disconnect the city power first, then disconnect the battery cable.

for electric bike using 12v battery charger for 12v 40ah lead acid batteries

for electric bike using 12v battery charger for 12v 40ah lead acid batteriesfor electric bike using 12v battery charger for 12v 40ah lead acid batteriesfor electric bike using 12v battery charger for 12v 40ah lead acid batteries

for electric bike using 12v battery charger for 12v 40ah lead acid batteries
