Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Specifications
Brand Name :
DLON
Model Number :
DL180-36V
Certification :
CE, RoHS
Place of Origin :
Guangzhou China
MOQ :
50 pcs
Price :
$21.0 ~ $26.00
Supply Ability :
10000 pcs per month
Packaging Details :
box and carton, 12 pcs/ carton
Size :
155*90*50mm
Weight :
1.0 Kg
Input Voltage :
85VAC-250VAC
Max wattage :
180W
Ambient temperature :
-20 °C to +50°C
Protection :
SCP,OVP,OCP,OTP
Application range :
scooter,E-bicycle,E-motorcycle,tourism bus,floor washer,golf cart etc
Warranty :
18 months
Description

Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale

Brief description :
1. Aluminium case , light weight
2. Input voltage ; AC 100 V ~240 V 50 / 60 HZ
3. Max wattage : 180 W
4. Charge mode : 3 stage ( CC CV float mode )
5. Charging : High saturation and efficiency
6. Input plug(power cords) : EU US UK AUS Italy Plugs etc ( can be Customized)
7. Output Connector : DC jack, XLR, JST, Cigar Lighter, Alligator Clips etc


The 180w battery charger specification :

Nominal

Output Voltage		 CV CC Transition / Cut-off Current Net Weight Size
Lead Acid Li-MnO2 LiFePO4 A Lead Acid (A) Li(A) (kg) (mm)
DL180-12V 14.7V 16.8V 14.6V 8A 1.6 0.4 1.0 155*90*50
DL180-24V 29.4V 29.4V 29.2V 5A 1.0 0.25
DL180-36V 44.1V 42.0V 43.8V 4A 0.8 0.2
DL180-48V 58.8V 54.6V 58.4V 3A 0.6 0.15


Note: Cut-off point for Li battery is 5% of CC, and it can be setted between 3-10%.

The battery charger structure as follows :
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale

Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesaleStronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesaleStronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Charging Procedure :

  1. First output power charger wire ends are connected to the battery anode and cathode , the charge indicator turns green, the connection is correct, otherwise the charge in question, please check the actual situation.
  2. Then city power plug to socket , the indicator is red, charger will be into the charging state .
  3. When the indicator light turns to green, the battery is charged to 95% , If you want to reach 100% , keep charging for 1 to 2 hours before end of charge.
  4. When fully charged, disconnect the city power first, then disconnect the battery cable.


Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale

Package & Delivery
1. Package : one piece one neutral box , 12 pcs/ carton, can be customized
2. Delivery : 5 to 7 working days , big order according to actual quantity
3. Delivery port : Guangzhou port
4. Payment term : T/T or Western Union
5. Delivery way : by sea / by air / by express or as your requirement
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale


Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
Stronger power supply 80ah 43.8v lifepo4 battery charger electric toy car power charger for wholesale
