• Inconel Series

The Nickel Inconel 625 is a non-magnetic nickel-chromium superalloy that features superb corrosion resistance as expected by the presence of the aforementioned transition metals. Moreover, it is very strong and is characterized by the wide range of its fabrication possibilities.

The safe operating temperature range of Nickel Inconel 625 spans from -238℉ (-150℃) to up to 1800℉ (982℃), so it can be used in a wide spectrum of applications that require exceptional corrosion resistance characteristics.

Variable temperatures are not the only thing that the Inconel 625 can withstand, as the same applies for variable pressures and very harsh environments that induce high rates of oxidation. In general, it finds application in sea-water applications, the chemical processing industry, the nuclear energy field, and also the aerospace sector.

As it is evident from the latter especially, the Inconel 625 is also very resistant to cracking, rupture and creeping damage, featuring high tensile strength and extraordinary corrosion versatility.

• Chemical Properties of Inconel 625

• Application

Some typical applications are:

1. The core of mooring cables
2. Submarine propeller blades
3. Submarine propulsion unit caging
4. Navy boat exhaust ducts
5. Undersea communication cables sheathing
6. Other submerged systems or instruments
7. Aircraft ducts and exhausts
8. Thrust-reversers
9. Engine compartment housing
10. Fuel and hydraulics tubing
11. Turbine seals
12. Reactor core components
13. Fuel control rod components
14. General plant equipment
15. Vessels
16. Honeycomb heat exchangers
17. Various types of industrial tubing
18. Distillation columns
19. Valves
20. Super-heated potassium and sodium solar power stations tubing

• ,Type we could offer

  AMS Number	Alloy	Type	UNS	Cross Ref. Spec	Misc./Shape
  AMS 5581	Inconel 625	Nickel	N06625
  AMS 5581 Custom Tube	Inconel 625	Nickel	N06625	-	Custom Tube
  AMS 5581 Tubing	Inconel 625	Nickel	N06625	-	Tubing
  AMS 5599	Inconel 625	Nickel	N06625
  AMS 5599 Plate	Inconel 625	Nickel	N06625	-	Plate
  AMS 5599 Sheet	Inconel 625	Nickel	N06625	-	Sheet
  AMS 5599 Strip	Inconel 625	Nickel	N06625	-	Strip
  AMS 5666	Inconel 625	Nickel	N06625
  AMS 5666 Bar	Inconel 625	Nickel	N06625	-	Bar
  AMS 5666 Custom Tube	Inconel 625	Nickel	N06625	-	Custom Tube
  AMS 5666 Forging	Inconel 625	Nickel	N06625	-	Forging
  AMS 5666 Ring	Inconel 625	Nickel	N06625	-	Ring
  AMS 5869	Inconel 625	Nickel	N06625
  AMS 5869 Plate	Inconel 625	Nickel	N06625	-	Plate
  AMS 5869 Sheet	Inconel 625	Nickel	N06625	-	Sheet
  AMS 5869 Strip	Inconel 625	Nickel	N06625	-	Strip
