SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
Specifications
Brand Name :
DockFender
Model Number :
DF-C1800H
Certification :
PIANC, SGS, DNV
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
USD900-3900
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2900 PCS Per Month
Delivery Time :
5-8 Work Days
Packaging Details :
Plastic Protective Film, Wooden Pallet
Product Name :
Heavy Duty 1800H Cone Rubber Fenders Dock Boat Bumper Protection Tear Resistance
Material :
Wear Resistant NR
Processing Service :
Moulding
Packing :
Bare Packing, Frame Packing, Pallet Packing
Size :
500-2000H
Approved :
SGS, ABS, ISO9001, PIANC
Applications :
Dock Boat Protection
Description

Heavy Duty 1800H Cone Rubber Fenders Dock Boat Bumper Protection Tear Resistance

Description

Technological evolution from the cell fender brings us to the production of cone fenders that not only exhibits low reaction force upon contact, but also carries great energy absorption capacity. In addition, cone rubber fenders can take high berthing angles and still be efficient.

Its conical design provides a large circular base that keeps the fender body stable at all times no matter the shear, axial or angular force. Cone Rubber Fenders system can be used for berthing for most ship types like RoRo, Tanker, Cruise berths etc & structures including but not limited to container & bulk terminals, general cargo facilities.

Specifications

Product Name Heavy Duty 1800H Cone Rubber Fenders Dock Boat Bumper Protection Tear Resistance
Brand Name DockFender
Model Number DF-C1800H
Material Natural Rubber, SBR, NBR
Standard PIANC2002, ISO9001
Hardness ≤82 Shore A
Processing Service Moulding
Performance Ageing resistance, ozone resistance, oil resistance
Color Any color is OK
Drawing Format Available according to design in production
Package Inner-Plastic Bag; Outer -Standard Pallets, wooden case or as your demand
Usage Multi-Purpose-Terminals, RoRo ramps, Passenger Vessel Terminals, Barge
Service Warm and quick response service provided by the professional Export Sales Team with many years' experience in handling exports to the US, Europe, Australia and other countries.

SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance

Model H h F D Q W d-m d-n
Cone [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]
DF-300H 300 13.5 255 450 195 405 M16 20
DF-350H 350 25 300 570 235 510 M20 25
DF-400H 400 18 340 600 260 540 M20 25
DF-500H 500 25 425 750 325 675 M24 30
DF-600H 600 27 510 900 390 810 M24 30
DF-700H 700 32 585 1050 455 945 M30 38
DF-800H 800 36 680 1200 520 1080 M36 44
DF-900H 900 41 765 1350 585 1215 M36 44
DF-1000H 1000 45 850 1500 650 1350 M42 56
DF-1050H 1050 55 1030 1680 900 1530 M36 44
DF-1100H 1100 50 935 1650 715 1485 M42 50
DF-1150H 1150 52 998 1725 750 1550 M42 56
DF-1200H 1200 54 1020 1800 780 1620 M42 50
DF-1300H 1300 59 1105 1950 845 1755 M48 60
DF-1400H 1400 66 1190 2100 930 1890 M48 60
DF-1600H 1600 72 1360 2400 1060 2160 M48 70
DF-1800H 1800 78 1530 2880 1190 2430 M56 76
DF-2000H 2000 80 1900 3200 1540 2920 M56 76

Installation Accessories

Front Panel: Reduces surface pressure and avoids damage to fenders and boats.

Face Panel: Reduce the coefficient of friction to protect the hull. Ultra-high molecular weight polyethylene.

Pre-installed Bolts and Nuts: Used to secure the fender to the dock. 1Cr18Ni9Ti, SUS304, SUS316 stainless steel or Q235 hot dip galvanized.

Preset U-Rings: Secure the chain. Q235 painted or hot dip galvanized.

Anchor Bolt: Connect accessories such as fenders and front panels. Stainless steel (or hot dip galvanized).

Weight Chain: Supports the front panel to avoid sagging. 1Cr18Ni9Ti, SUS304, SUS316 stainless steel or Q235 hot dip galvanized.

Tension Chain: When the lower part of the fender is stressed, it limits the deflection of the fender. Q235 hot dip galvanized or painted.

Shear Chain: Prevents shear deformation of the fender system. Q235 hot dip galvanized or painted.

Features

1. Highly efficient shape

2. Excellent under large berthing angles and shear

3. Versatile design suits numerous applications

4. Choice of standard & intermediate compounds

5. Stable geometry maintains performance under all loading combinations

Applications

● Container & Bulk Terminals

● Oil & Gas Terminals

● General Cargo Terminals

● RoRo & cruise terminals

● Dolphins & monopiles

● Navy

SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance

SBR NBR Super Cone Fender Dock Boat Bumper Protection Tear Resistance
