Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Chemical STS Hose Chemical Resistance Oil Lightweight Design
Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-SH14
Certification :
ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
Place of Origin :
China
MOQ :
1
Price :
USD13 to USD 6600 Per Piece
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1800 Pieces Per Month
Delivery Time :
5-6 Work Days
Packaging Details :
Wooden pallets, Wooden cases or as required
Product Name :
STS Hose
Flange :
ANSI150, ANSI300
Standard :
OCIMF2009, EN1765
Warranty :
24 Months
Pressure :
10-21 Bar
Test :
Hydraulic Pressure Bending Radius
Inner Rubber :
NBR
Model :
HM-SH14
Reinforcement :
High Strength Synthetic Cord with Sprial Steel Wirehose
Keywords :
Discharge Hose Pipe
Cover :
Nr+Orange Spiraled Stripe
Description

Chemical STS Hose Chemical Resistance Oil Lightweight Design

Description

The High-Pressure STS Marine Transfer Hose represents the pinnacle of marine cargo transfer technology, specifically engineered to handle extreme pressure conditions and challenging marine environments. Featuring a specialized inner lining and robust external reinforcement, this hose can withstand significant operational pressures while maintaining optimal flexibility and performance. Its advanced construction ensures maximum safety and efficiency during ship-to-ship transfer operations.
This innovative hose offers numerous advantages, including exceptional pressure resistance up to 25 bar, superior chemical compatibility, and remarkable abrasion resistance. It is particularly suitable for complex marine transfer operations involving crude oil, refined products, and chemical substances. The hose's unique design minimizes product loss, reduces environmental risks, and provides unprecedented reliability in the most demanding maritime transfer scenarios.

Chemical STS Hose Chemical Resistance Oil Lightweight DesignChemical STS Hose Chemical Resistance Oil Lightweight Design

Specifications

Material PTFE, Galvanized Steel Wire, PVC Coated Polyester Cloth
Product Name Chemical STS Hose Chemical Resistance Oil Lightweight Design
Size HM-SH14
Inner Wire Stainless Steel 316
Lining Polyamide
Carcass Polyamide fabrics, Polyester films
Outer Wire Stainless Steel 316
Working Pressure 10 bar to 21 bar
Maximum Length 40 meters
Sample Available
Delivery time Normally 3-5 days

Model Dimensions Working Pressure Safety Factor Bending Radius Weight Length
Composite [mm] [inch] [bar] [psi] [kg] [m]
HM-SH20 20 3/4" 16 230 6:1 80 0.8 40
HM-SH25 25 1" 16 230 6:1 100 1 40
HM-SH32 32 11/4" 16 230 6:1 125 1.3 40
HM-SH40 40 11/2" 16 230 6:1 140 1.5 40
HM-SH50 50 2" 16 230 6:1 180 2.5 40
HM-SH65 65 21/2" 16 230 6:1 200 3.3 40
HM-SH80 80 3" 16 230 6:1 260 4 40
HM-SH100 100 4" 16 230 6:1 380 6.8 40
HM-SH125 125 5" 16 230 6:1 440 9.2 40
HM-SH150 150 6" 16 230 6:1 500 13.2 40
HM-SH200 200 8" 16 230 6:1 750 18 40
HM-SH250 250 10" 16 230 6:1 900 26 25
*Note: Various sizes can be customized according to the requirements.

Features

Safety Compliance

STS hoses are manufactured to meet rigorous safety standards, minimizing the risk of leaks or failures, thereby protecting both personnel and the environment.

Temperature Resistance

Capable of withstanding extreme temperatures, STS hoses perform reliably in both high-heat and cryogenic applications, expanding their usability across different sectors.

Low Maintenance

Designed for minimal upkeep, STS hoses reduce operational costs by decreasing the need for frequent replacements or repairs, ensuring uninterrupted workflow.

Smooth Inner Surface

The hoses feature a smooth inner lining that promotes efficient fluid flow and reduces turbulence, ultimately enhancing performance and longevity.

Applications

● Oil Transfer Operations

● Loading and Unloading of Fuel
● Ship Waste Disposal
● Chemical Transfer

Advantages

Reliable Performance
Our STS hoses are designed to withstand extreme conditions, ensuring reliable performance in the most demanding applications, which our clients have come to trust over the years.
Experienced Workforce
Our team consists of highly skilled professionals with extensive knowledge in hose manufacturing, allowing us to maintain a strong reputation for craftsmanship and attention to detail.
Comprehensive Product Range
We offer a wide variety of STS hoses suitable for diverse applications, from fuel transfer to chemical handling, ensuring we can support all your needs.
Sustainability Focus
We are dedicated to sustainable manufacturing practices, minimizing waste and using environmentally friendly materials to promote a healthier planet.

Chemical STS Hose Chemical Resistance Oil Lightweight Design

Chemical STS Hose Chemical Resistance Oil Lightweight DesignChemical STS Hose Chemical Resistance Oil Lightweight Design


FAQ

Q: What is the minimum order quantity for the STS Hose?
A: The minimum order quantity for the STS Hose is 1.
Q: What is the price range for the STS Hose?
A: The price range for the STS Hose is between $100-$900.
Q: What are the packaging details for the STS Hose?
A: The packaging details for the STS Hose are as required.
Q: What is the delivery time for the STS Hose?
A: The delivery time for the STS Hose is 10 days.
Q: What are the payment terms for the STS Hose?
A: The payment terms for the STS Hose are T/T and L/C.
