pressurized solar thermal collector
pressurized solar thermal collector
Specifications
Place of Origin :
Changzhou, China
Brand Name :
Dr.X Solar
Certification :
CE, ISO9001, CCC
Model Number :
58/1800-15
Manifold casing :
aluminum alloy 2.0mm
Stand :
aluminum alloy 2.0mm
flow channel :
copper pipe
heat pipe :
copper TU2, condensor 14mm diameter, 0.6mm wall thick
working pressure :
0.6Mpa
Insulation :
rock wool
MOQ :
1pcs
Price :
170- 260USD
Packaging Details :
carton box or wooden box
Delivery Time :
14days
Payment Terms :
T/T, 30% deposit in advanced, rest paid before shipping
Supply Ability :
2000pcs/ month
Description

Pressurized solar thermal collector 58/1800-15

Specialty:

1. High heat collecting efficiency, and high temperature output.

2. Quick operation under pressure.

3. Strong freezing resistance, no water leakage problem.

4. easy installation, and convenient maintenance.

5. Completely combine with building, install on wall , roof, or ground etc.

Technical Specification:

1. Manifold outer casing material: aluminum alloy 2.0mm thickness.

2. Head pipe material: copper

3. Insulation material: rock wool

4. Heat pipe material: copper

5. Stand frame material: aluminum alloy 2.0mm

6. Vacuum tube: borosilicate glass 3.3, Cu/ALN-SS/ALN coating.

7. Collector mounting: for flat roof or slope roof

8. Working pressure: 0.6Mpa

Production flow:
