G2F MAXHUB Large Capacitive Touch Screen Panel Nano Silver
G2F MAXHUB Large Capacitive Touch Screen Panel Nano Silver
G2F MAXHUB Large Capacitive Touch Screen Panel Nano Silver
G2F MAXHUB Large Capacitive Touch Screen Panel Nano Silver
Specifications
Brand Name :
Lunfeng
Model Number :
CTP231053
Certification :
ISO9001: 2015
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Payment Terms :
T/T, Western Union
Supply Ability :
500000 Piece/Pieces per Month
Delivery Time :
7-25 working days, To be negotiated
Packaging Details :
First put into a polybag, then paked into a carton. According to clients' special requirements.
Name :
Large Size 65" To 86" MAXHUB Capacitive Touch Screen Panel
Application :
Medical Equipment, Electronic equipment, Home Appliance/Telecommunication Equipment...
Structure :
Nano Silver, sensor, GFF, G2F
Material :
FILM/GLASS
Size :
55"-100", Customized Size
Membrane switch :
OEM Membrane Switch
Touch Solution :
Glass-Glass（G+G）,Glass-Film（G+F）, Glass-Film-Film （G+F+F）, Glass-Flim2（G+F2）
Description
Product name:
Large Size 65" To 86" MAXHUB Capacitive Touch Screen Panel
Specification
> Touch solution:
Glass-Glass(G+G),
Glass-Film(G+F),
Glass-Film-Film (G+F+F),
Glass-Flim2(G+F2)
> Touch size: 50-100" big size, mainly 65"-86"

Specification of Infrared Touch Screen
Touch Screen Size
86"
Touch Points
20-point touch
Minimum Recognition Point Size
4mm*4mm
Supporting resolution
32768×32768
Touch Response Time(Multi touch)
10-15ms
Touch Response Time(One touch)
7ms
Input method
Any opaque touches, such as fingers, brushes, etc.
calibration
4-point calibration
Number of clicks
Infinite times
Touch pressure
No pressure requirement
Interface type
1.5 m USB cable receptacle, the receptacle 5P
Line length
1.5m
Frame Material
Aluminium alloy
Glass Material
Toughened glass
Characteristic
Easy installation, strong compatibility
Scanning frequency
>110Hz
communication interface
USB 2.0
Power supply mode
USB 5.0V
Working Voltage and Current
4.75~5.25V , ≤200mA
Humidity
Up to 90% RH from 0°C to +40°C, non-condensing
Temperature Range
Working temperature:-10℃～50℃,Storage temperature:-20℃～60℃
LED Lifetime
60000hours
Fault-tolerant
Able to work if less than

10% non-consecutive sensors are damaged
Anti-light Interference
Excellent
ESD
EN 6100-4-2 2008:3 level.4KV contact discharge and

8KV air discharge
Firmware Upgrade
USB Upgrade: Windows 8,Windows 7
Support OS(Multi touch)
Windows10,Windows8,Windows7,Andriod
Support OS (One touch)
WindowsXP,MacOS.Linux

Infrared Touch Application Scene

1.education
2.Medical industry
3.Finance
4.Exhibition
5.Industrial control
6.Man-machine interaction
7.TV
8.PC
9.And more
