stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter mesh
Specifications
Brand Name :
Dongce
Model Number :
SGS 20200512252
Certification :
SGSQIP-ASI216066
Place of Origin :
Anping,China
MOQ :
100 units
Price :
Discuss
Supply Ability :
50000 units per week
Packaging Details :
Plastic bag or film, Then by carton or wooden pallet
Usage: :
Air Filter
Type: :
Filter Disc
Thickness: :
0.35-3.0mm
Length: :
5mm to 600mm
Width: :
5mm to 600mm
Item: :
filter mesh disc
Weave style: :
Plain Dutch Perfoated
Structure: :
Single layer double layer Multi Layer
Technique: :
spot welded, seal welded, edge covering etc
Shape: :
Rectangle, Square, Round, oval, and abnormity etc.
Description

20 Micron stainless steel wire mesh Round mesh metal filter screen filter disc
Product Description

1. Purpose: SPL filter is also called laminated filter filter, disc filter, which is made of metal meshes of different meshes combined with support meshes and processed by edging. SPL filter is a filter made of metal wire mesh, which has the characteristics of high strength, large oil passing capacity, reliable filtration and easy cleaning. Suitable for filter press oil filtration, oil system filtration of marine diesel engines and other equipment, and chemical fiber engineering In the industry, the front side of various types of spinning nozzles for synthetic fiber and man-made fiber textiles and other similar conditions are used to filter impurities in the textile stock solution. The mesh type oil filter is divided into SPL double cylinder series and DPL single cylinder series. The oil filter is reliable in operation and convenient in maintenance. It does not require other power sources. The filter element is a filter made of wire mesh, which has high strength and oil passing capacity. Big, guaranteed With the characteristics of filtration accuracy and easy cleaning, the SPL double-cylinder series can realize non-stop conversion and cleaning during the operation of the host.

2. Performance characteristics (1). Filter made of metal wire mesh (2). It has high strength and large oil flow capacity (3) Features such as reliable filtration and easy cleaning

3. Technical parameters: (1) Applicable nominal diameter: 15-200mm (2) Flow rate: 2-320L/min (3) Filtration accuracy: 5-400um (4) Filter material: phosphor bronze mesh, stainless steel smooth mesh, twill mesh, mat mesh (5) High working temperature: 95ºC (6) High working pressure: 0.8Mpa
Product Specification

Specification List of Stainless Steel Wire Mesh
Mesh/Inch Wire Diameter(mm) Aperture (mm) Filters Area% Mesh/Inch Wire Diameter(mm) Aperture
(mm)		 Filters Area%
2 1.60 11.10 76 80 0.13 0.187 35
3 1.60 6.87 66 100/90 0.10 0.167 39
4 1.60 4.75 56 100 0.10 0.154 37
5 1.00 4.08 64 100 0.11 0.144 32
6 0.90 3.33 62 120 0.09 0.122 33
8 0.90 2.28 51 120 0.08 0.132 39
8 0.70 2.47 61 150 0.065 0.104 38
10 0.50 2.04 64 200 0.05 0.077 37
12 0.50 1.62 59 200 0.04 0.084 47
14 0.50 0.50 52 250 0.04 0.062 37
16 0.35 1.24 61 250 0.035 0.067 43
18 0.28 1.13 64 250 0.03 0.072 50
20 0.35 0.92 52 300 0.04 0.045 28
24 0.35 0.71 45 300 0.03 0.055 42
28 0.35 0.56 38 325 0.035 0.043 30
30 0.28 0.57 45 325 0.028 0.050 41
40 0.22 0.42 43 400 0.030 0.034 28
50 0.18 0.33 42 400 0.023 0.042 43
60 0.16 0.26 39 508 0.025 0.025 26
70 0.14 0.223 38 635 0.018 0.0203 25

Product Images
Filter medium for Disc Filters is multi-layer sintered wirecloth, with a rating range from 0.5 to 200micron, in a diameterfrom 200mm to 3000mm. Disc filters with multi- layer sinteredwire cloth as filter medium, enjoy good strength, accurate filterrating, long life-span and repeatedly cleaning. Materials: Standard material of disc filters is SUS3l6L. Othermetals like Nickel alloy or Titanium alloy are also available at customers request. Application: Disc filters are ideal filter fittings for three- -in-one filtration (filtering, washing and drying) in pharmaceutics,food, chemical industries and polymers. Disc filters work as a complete unit or in parts. Disc filters Series Disc Filter Model: DF-D-R, DF-DiscFilter, DDiameter, RFilter Rating



Packaging
stainless steel wire mesh metal filter multi-layer mesh filter screen filter ,100 micron stainless steel filter meshFAQ
1. who are we?
We are based in Henan, China, start from 2017,sell to North America(30.00%),South America(20.00%),Eastern Europe(15.00%),Mid East(15.00%),Southeast Asia(10.00%),Africa(10.00%),Oceania(10.00%). There are total about null people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
filter,filter element,Oil filter,Power plant sampling accessories

4. why should you buy from us not from other suppliers?
Xinxiang Zhengan filtration equipment Co., Ltd. is a large high-tech enterprise integrating scientific research, production, sales and service.The company has advanced production technology,Won the trust of the majority of users.

5. what services can we provide?
Accepted Delivery Terms: null;
Accepted Payment Currency:null;
Accepted Payment Type: T/T,PayPal;
Language Spoken:English,Chinese
Contact Us

Contact Information : Ms.Miya

Business Phone : +86 15631823903

Wahtsapp: +86 15631823903

Wechat : +86 15631823903
