Specifications
Brand Name :
DONJOY
Model Number :
NO.VDF301Q1
Certification :
CE,3A,FDA
Place of Origin :
China
MOQ :
1
Price :
negotiation
Payment Terms :
T/T, LC, Credit Card
Supply Ability :
50 sets 20 working days
Delivery Time :
10-30 working days
Packaging Details :
Carton box/Wooden box
Product Name :
Pneumatic double seat butterfly valve
Materials :
304 / 316L
Size :
DN50-DN100,2"-4"
Operation :
Actuator
Connection :
welding
Seal standard :
3A certification
Temperature :
-10℃ to 130℃
Max pressure :
10 bar
Description

3A CE DONJOY pneumatic double seat butterfly valve with position feedback unit F-TOP

specifications

Product Name:

 3A CE DONJOY pneumatic double seat butterfly valve with position feedback unit F-TOP

Valve Body Material:

SS304/316L

Seal Material:

EPDM (standard) FPM/SILICON/NBR, FDA177.2600

Max Working Pressure:

10Bar,PN16

Max.Working Temperature:

130 degree C

Available size:

DN50-DN100, 2"-4"

Available connection:

welding / thread /Clamp/ special connection

Available standard:

3A/DIN/SMS/RJT/ISO/IDF

Operated:

Manual,Pneumatic

Handle application:

Pull handle

Control:

Smart valve positioner / C-TOP control / position sensor

Certificate:

3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO

Application scope:

Dairy,food, beverage, pharmacy, cosmetic, etc

Feature of structure:

Mixing proof butterfly valve with position feedback unit F-TOP

Option:

With smart head C-TOP or Positioner IL-TOP


Classification
Mixture proof butterfly valve;
Double seat butterfly valve;
Single seat butterfly valve;
Material
The material connected with others: AISI 316L / 1.4404
The material in other part: AISI 304
Seal ring: EPDM FDA 177.2600
Inernal surface finish: Ra ≤ 0.8μm
External surface finish: CNC fine machining
Options
Gasket: NBR / MVQ / FPM
Pneumatic actuator of double acting
Inductive position sensor
C - TOP control head
Position sensor

Handle selection
Pull handle


Connection
SMS, RJT, DIN, 3A, ISO, Clamped, welded and threaded etc.

Packaging Details
Bubble pack for each valve.
outside packing are carton or plywood cases.
Or as per the request of customers.

Delivery details
Usually within 20 days after receiving T/T down payment.
Drawing
3A CE Pneumatic Double Seat 4



Performance of different sealing material
3A CE Pneumatic Double Seat 4
3A CE Pneumatic Double Seat 4
3A CE Pneumatic Double Seat 4
