No Touch Exit Sensor Door Exist Button Door Entry Switch Built - In Sounder Buzzer
No Touch Exit Sensor Door Exist Button Door Entry Switch Built - In Sounder Buzzer
Specifications
Brand Name :
CAMEL
Model Number :
SNT840
Certification :
CE RoHS
Place of Origin :
China
MOQ :
10pcs
Price :
reasonable factory-direct prices
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
30,000pcs per month
Delivery Time :
5-8 days
Packaging Details :
paperbox for each unit; carton box for 100pcs at dimension 52*43*32cm
Product Name :
Touchless Sensor Exit Button
Input :
3A @12-24V DC
Cable Wires :
NO/NC/COM/+12V/GND
LED Indicator :
Blue for standby and Green for active
Material :
Stainless steel, Metal Button
Dimension :
115L*40W*25H(mm)
Package :
100pcs/12kg/51*43*33cm/ctn
Certificates :
CE&RoHS
Description

Touchless Exit Button Narrow Long Size Stainless Steel Plate

Key Features of SNT840 touchless exit button

1, the switch can be activated by a simple hand wave or approach-sanitary and easier access.

2, NO and NC output for all kinds of locks

3, no moving parts - more durable

4, two LED indicator provide visual confirmation for standby (Blue) and operated/actived (Green)

5, built-in sounder buzzer

6, single gang plate fits flush box, we also provide ANSI Size 115*70 plate, European Size 86*86 plate and 86*50 plate, surface mounting backbox

7, 12-24V DC

8.M40 Backbox is available

9, CE RoHS Certificated

10, 3 years warranty

11, experienced sales person with full support

Product Name

no touch to exit button, rex touchless, touchless rex, no touch request to exit, touchless sensor button, touchless sensitive, exit button

Description

Camel Security SNT840 is a hollow narrow size IR Sensor no touch to exit button with 304 Stainless Steel plate for indoor use. With touchless sensitive switch unit designed for use with access control system or connect to electric locks. It is an ideal replacement for conventional push buttons, door release button etc.

Technical Parameter

dimension 115L*40W*25H(mm) = 4.52L*1.57W*0.98H(inch)
input 3A@ 12-24V DC
output NO/NC/COM
standard structure: 304 stainless steel plate, steel button
working temperature -20‐+55℃ (14-131F)
working humidity 0-95% (non-condensing)
LED indicator

white LED indicator Power Off

Blue LED Indicator Standby

Green LED Indicator Active
weight 0.12kg

Product Pictures

No Touch Exit Sensor Door Exist Button Door Entry Switch Built - In Sounder Buzzer

No Touch Exit Sensor Door Exist Button Door Entry Switch Built - In Sounder Buzzer
