Specifications
Brand Name :
MCD
Model Number :
MCD-10080
Certification :
ISO , CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T , Western Union , L/C
Supply Ability :
300 set/month
Delivery Time :
Normally within 5 working days
Packaging Details :
Wooden Case Package
Tunnel Size :
1000(W)*800(H)mm
Conveyor Speed :
0.22m/s
Conveyor Max Load :
200kg
Penetration :
40mm Steel
MOQ :
1set
Warranty :
12 Months
Film Safety :
Guarantee ISO1600 Film
Penetrate Resotlution :
dia 0.511mm
Generate direct :
downward
Generate angle :
80 degree
Anode Voltage :
100-160 kv
Anode power :
0.4 to 1.2 mA
Description

Best Quality baggage x ray scanner X Ray Security Scanner With 100cm X 80cm Tunnel size MCD10080 X-ray baggage scanner

Description:

Large tunnel size, bulky items rays may penetrate inspection, the object can be found inside the metal

structure, showing the naked eye can not see where the liquid is also very obvious object display. Used

in the factory testing of security products and business units such as: electronic factories, shoe

factories,

toy factories, courts, railway stations, and event bag, line security management package. Assist to

detect drug and explosive power.

Parameter :

Tunnel Size 1000(W)*800(H)mm
Conveyor Speed 0.22m/s
Conveyor Max Load 0kg
Dose per Inspection <1.4Gy/h
Resolution < 0.101mm Copper Wire
Spatial resolution Level dia1.3mm
Vertical dia1.0mm
Penetrate resolution dia 0.511mm
Penetration 40mm Steel
Film Safety Guarantee ISO1600 Film
X-ray Leakage <0.1 μGy/h (at a distance of 5cm From external housing)

X-Ray generator:

Generate direct: Downward

Generate anger: 80 degree

Anode Voltage: 100~160Kv

Anode power: 0.4 to 1.2mA

Cooling / Duty Cycle: Oil Cooling /100%

Image System

X-ray Sensor L-Shaped Photodiode Array (monoenergetic) , 12bit Deep
Monitor High Resolution Color, LCD Accord, 17 inch
Detector 2
Color display full color
Image Processing

Edge enhancement, image strengthening, Image lightening,

reducing darkening, image returning, image retrieval.
Image Grey Level 4096
Image Max Resolution 1024 * 1280 pixel
Image Processing 24bit for processing real time
Image storage Storage 60000 pictures in real time
Zones & Zoom

1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen

continuous observation
Multi-energeti distinguish objects

organic objects in orange,inorganic objects in blue,

mixture in green
High-energy/low energy

switch from high energy to low energy

Installation Data:

Operation temperature/Humidity 0°C-45°C/20%-95%(non-condensing)
Storage Temperature/Humidity -20°C-60°C/20%-95%(non-condensing)
Operation Power 220VAC(±10%)50±3Hz
Power Consumption 1.0 KW (max), 1.0KW(working)
Noise: <58db

Applications:

  • Commercial buildings
  • Factories
  • Courthouses
  • Embassies
  • Government buildings
  • Military installations
  • Prisons
  • Hotels
  • Schools
  • Convention centers
  • Security checkpoints

Competitive Advantage:

  • Innovative & Economical

  • World Class Reliability
  • Long-Term Flexibility
  • Ease of Use Increases Efficiencies
  • Ease of Maintenance

  • Competitive Price and Professional Service

MCD10080 X Ray Baggage Scanner 100cm X 80cm Tunnel Size 12 Months Warranty

Shipping Means

  1. By express (3-5days, most expensive)
  2. By air (5-7days, expensive)
  3. By sea (15-28days, cheapest)

MCD has been supplying quality products worldwide for over,40 countries, 10 years, with wide range product line consists of 6 groups, includes:

  • X-ray luggage scanner
  • Walkthrough metal detector gate
  • Food metal detector
  • Underground metal detector
  • Hand-held metal detector
  • Under Vehicle search system
