Specifications
Brand Name :
MCD
Model Number :
MCD-F500QF
Certification :
ISO , CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T , Western Union , L/C
Supply Ability :
100 set/month
Delivery Time :
Normally within 5 working days
Packaging Details :
Strong Wooden Case
Detecting Method :
the electromagnetic wave detection, the new analog circuits and digital
Detecting width :
45-80 cm, Customized
Detecting height :
10-50cm Customized
Sensitivity adjust :
0-10 Level
Conveyor Belt Speed :
25m/min
Power Supply :
AC100-265V , 50-60Hz
Display way : :
7 inch digital circuit full-color touch pannel LCD display
Alarm Method: :
The buzzer alarm, the motor automatically stop
Description

Cheap Price Machine Food Metal Dectator MCD-F500QF

Description:

MCD-F500QF is new arrival food metal detector.Not only it has MCD-F500QD and MCD-F500QE all

advantages.like touch screen ,10 level adjustable sensitivity and memory 10 kinds of products etc.
But also it has more higher reliablity and stablity on check products with water and salt.

Quick detail:

Detection method:

the electromagnetic wave detection, the new analog circuits
and digital circuits combined
Display way : 7 inch digital circuit full-color touch pannel LCD display

Detection width :

45-80 cm, Customized

Detection height:

10-50cm Customized

Sensitivity adjustable:

0-9 level

Detection sensitivity:

0.6mm-3.0mm iron ball, 1.5mm-5.0mm Stainless steel

Alarm mode:

The buzzer alarm, the motor automatically stop

Transfer speed:

25 meter / mins

Power:

100-265VAC, 50-60Hz

Size:

(150-170)(L)*(80-90)(W)*(85-120)(H)cm

Metal Detector Parameters :

Model

Detecting height(cm)

 Detecting width(cm)

Sensitivity(mm)

 Belt Size(cm)
Fe SUS Length Width

MCD-F500QF-09

 6 30 Φ0.6 Φ1.2 258 28
MCD-F500QF-12 9 30 Φ0.7 Φ1.5 258 28
MCD-F500QF-15 12 40 Φ0.8 Φ1.5-Φ2.0 258 38
MCD-F500QF-20 17 40 Φ1.0-Φ1.25 Φ2.0-Φ2.5 258 38
MCD-F500QF-25 22 50 Φ1.5-Φ2.0 Φ3.0-Φ4.0 330 48
MCD-F500QF-30 27 50 Φ2.5-Φ3.0 Φ5.0-Φ6.0 330 48
MCD-F500QF-35 32 60 Φ3.0-Φ3.5 Φ6.0-Φ7.0 330 58
MCD-F500QF-40 37 60 Φ3.5-Φ4.0 Φ7.0-Φ8.0 330 58
MCD-F500QF-45 42 70 Φ4.0-Φ4.5 Φ8.0-Φ9.0 330 68
MCD-F500QF-50 47 70 Φ4.5-Φ5.0 Φ9.0-Φ10.0 390 68
MCD-F500QF-55 52 80 Φ5.0-Φ5.5 Φ10.0-Φ11.0 390 78
MCD-F500QF-60 57 80 Φ5.5-Φ6.0 Φ11.0-Φ12.0 390 78
MCD-F500QF-65 62 90 Φ6.0-Φ6.5 Φ12.0-Φ13.0 390 88
MCD-F500QF-70 67 90 Φ6.5-Φ7.0 Φ13.0-Φ14.0 390 88
MCD-F500QF-75 72 100 Φ7.0-Φ7.5 Φ14.0-Φ15.0 450 98
MCD-F500QF-80 77 100 Φ7.5-Φ8.0 Φ15.0-Φ16.0 450 98
MCD-F500QF-85 82 110 Φ8.0-Φ8.5 Φ16.0-Φ17.0 450 108
MCD-F500QF-90 87 110 Φ8.5-Φ9.0 Φ17.0-Φ18.0 450 108
MCD-F500QF-95 92 120 Φ9.0-Φ9.5 Φ18.0-Φ19.0 450 118
MCD-F500QF-100 97 120 Φ9.5-Φ10.0 Φ19.0-Φ20.0 450 118

Remarks: it can't detecting aluminum foil and oxidizing agent , And other additional features should be customized, such as: infrared control, automatic rejecting device, foot switch, alarm indicator, control device, etc

Features and Application:

this machine is widely used in the detection of meat , mushrooms, candy, drinks ,food , fruits and,vegetables, dairy products , aquatic products , health products , additives and flavorings and other food-ferrousmetals and non-ferrous metal impurities.

Besides it can also be used for the detection of metallic impurities in

chemicals , rubber , plastics , textiles , leather , chemical fiber , toys as well as for the detection of metallic

impurities in pharmaceuticals , health products , biological products , cosmetics , gifts , packaging , papers,

and so on.

Arch 30cm Adjustable New Needle Food Metal Detector 90W Power MCD-F500QD

MCD-F500QF food metal detector.pdf

Company information:


*Established in 2005
*With more than 300 people, among of which R&D 15 staffs, QC 22 people
*Main products: X-Ray Luggage Scanner Handheld Metal Detector, Food Metal Detector, Underground Metal Detector, Under Vehicle Search System, Walkthrough Metal Detector Gate.
*Main market: Africa, South America, East Europe, Southeast Asia, Middle East etc.
*Certificates: ISO9001:2008, CE, RoHS, FCC, SONCAP
*Area: 12,000 Square meters

Welcome to contact us!Safety future, stability world
