4.3 Inch LED Screen Hotsale Surveillance Vehicle Equipment MCD-V7D
Basic Information:
Specification:
Items | Value | ||
Wireless | Wireless freq. | 2.4GHz–8 | CH1: 2414MHz; CH2: 2432MHz; |
Within 5.8G-A | CH1: 5865MHz; CH2: 5845MHz; | ||
Beyond 5.8G-B | CH1: 5705MHz; CH2: 5685MHz; | ||
Within 5.8G-C | CH1: 5733MHz; CH2: 5752MHz; | ||
Within 5.8G-D | CH1: 5740MHz; CH2: 5760MHz; | ||
Beyond 5.8G-E | CH1: 5705MHz; CH2: 5685MHz; | ||
Sensitivity | -92dB | ||
AV IN | TV system | NTSC / PAL | |
Output voltage | 3.6-4.2 V | ||
AV OUT | TV system | NTSC / PAL | |
HD 5-inch | Active area | 108mm(W) X 64.8mm(H) | |
Resolution | 800 X 480 Pixel | ||
Luminance for LCM | 200 cd/㎡ | ||
Video | Resolution | 720*576 / 720*480 | |
Video compress | MPEG-AVI 30fps | ||
Play format | MPEG-AV |
Items | Value | |
Audio | Subcarrier frequency | 2.4GHz:6.0MHz; 5.8G-A/B/C:6.5MHz; |
Earphone Frequency Range | 20HZ-20KHz stereo | |
Earphone Output | Left: 20MW+ right 20mW [16O](suit to | |
Speaker | 1W | |
Photo | Format | JPG/JPEG |
Storage | External SD card | TF card 1GB-32GB(optional) |
32GB recording time | 10-32 hours | |
1GB photos | 15625pcs | |
Operating system | PC | Windows & Mac OS |
Port | USB 2.0 | |
Language | Multiple | |
Power | Voltage | DC 5V |
Current(receiving mode) | 660MA | |
Current( recording mode) | 680MA | |
Current(recording with off-screen mode) | 340MA | |
AC adapter | DC 5V 2A | |
Built-in battery | Li-battery 3200Mah | |
Standby time | Wireless record | ≥9.5 hours(off-screen); ≥5hours(on-screen) |
Wired record | ≥12 hours(off-screen); ≥6hours(on-screen) *LED camera not included. | |
Size (L x W x H) | 131mm x 86mm x 18mm | |
Weight(g) | 205g |
Production Line
Shenzhen MCD Electronics Co.,Ltd. is a large-scale security equipment manufacturer, which interprets R&D, manufacturing and marketing together.Founded in 2005, MCD mainly concentrated on developing Metal Detector, Electronic Article Surveillance(ESA) devices, Food Packaging Testers, X-Ray Package Checkers, Under Vehicle Inspection Equipments, Explosion-proof equipments ect. Our products include Walk through Metal Detector Doors, Underground Metal Detectors, Handheld Metal Detectors, ESA for supermarkets andlibraries, Needle Detection Machines, X-ray Inspection equipments, Under Vehicle Inspection Mirrors, ect. Our products have been widely used inairports, embassies, army, prisons, prosecutions, government agencies, customs, ports, large public events and exhibitions, as well as places need valuablesecurity. Cooperating with many well-known foreign companies equipped us with strong technology strengths, speedy products development. With strict management regulations, our products strictly produced under the IS09001:2008standard. With more than 3000 square meters production workshop, full flowoperation, full-equipped production and testing equipments, we promise to offer the best products for our clients.
