Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
Specifications
Brand Name :
VIANS
Model Number :
VI-809ST
Certification :
CE/ROHS/FCC/MA
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
T/T or
Supply Ability :
5,000pcs per month
Delivery Time :
1-7 working days after received your payment
Packaging Details :
30 pcs/cartons
Face Plate :
260L*35W*48H(mm)
Strike :
100 L*25W*3H(mm)
Signal Output :
NO /NC/COM
Time Delay :
0/3/6/9 Sec
Voltage :
12V DC
Current :
Start 950mA, standby 150mA
Fail Secure :
Fail Safe and Fail secure (Option)
weight :
1.6KG
Description

Electric Bolt Lock for Important place,Drop Bolt Lock with Key for Bank,Prison

VIANS VI-809ST is Adjustable fail-safe (power to lock) or fail-secure (power to open).

1


Adjustable fail-safe (power to lock) or fail-secure (power to open).
2


Adjustable to fail-secure (power to open) for high security places. Adjustable to fail-safe (power to lock) for public places.
3


Built-in door open or door close state detection output point (250mA: N.C./ N.O.).
4


Suitable for 180° door.
5


Stainless steel bolt is able to sustain more than 800 kg of shear force.
6


Adjustable to fail-secure (power to open) to achieve long unlock state function.
7


Built-in oval cylinder as unlocking device. Use of oval cylinder to unlock when power cut occurred or during emergency.
8


Built-in photo couplers door open push button input contact. Door will lock again automatically when door is not open within 5 seconds.
9


Operation temperature: 0~90℃; Humidity: 85%Rh max.
10 Dimensions: Body: 260mm(L) x 35mm(W) x 48mm(D)
Strike plate : 100mm(L) x 25mm(W) x 3mm(D)
Bolt : 16mm(Throw) x 12.7mm(Diameter)

Product Parameter

Product Parameter Parameter Description
Lock Size 260L*35W*48H(mm)
Strike Size 100L*25 W*3H(mm)
Bolt 16MM X 12.7MM
Start Current 880mA
Working Current 320mA
Door Type Applicable Wooden door , Glass door ,Metal door , Fireproof door
Time Delay 0,3,6,9sec
Signal output YES
Security Type Key Open available
Weight 1.6KG



Features:

Photoelectricity Controling,no machanical defect.
Low Temperature, safe & Durable.
Low Power, Environmental Protection.
Long Life with 500000 cycles.
MOV Provides Reverse Current Protection.
Special photoelectricity control,three steps current application.
Superior Strength Aluminium Alloy,Solid Stainless Steel Bolt.
Working with cylinder cannot be copied,do increase security.
The humanized design of Led helps to indicate the working status of lock.
The applying of kirsite and Stainless Steel prevent the lock from high temperature,corrosion or damage.
With complete accessories,available for any doors.
Certificate:CE&MA.
Photoelectricity Control,Low Temperature,
A:The Low Current is Changed immediately;
B:When door frame doesn`t coincide with door leaf ,door leaf against the bolt,then the electric bolt will start the low-power function to bring low temperature.
C:The Photoelectricity Control Technology,prevent the machanical defect.


Installation drawing

Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key

Install At The Side Of The Door


Electric Drop Bolt Lock For Important Place , Electric Deadbolt Lock With Key
