Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments
Specifications
Brand Name :
STATEMED
Model Number :
STT9-ETU3
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Competitive
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
10 working days after payment received
Packaging Details :
standard export wooden case
Product Name :
Ear Nose Tthroat ENT Examination Unit
LED projection lamp :
≥8 W ; illuminate≥1×104
Sprayer :
Pressure: 0.1MPa～0.15MPa (adjustable)
Suction device :
≥0.07MPa (adjustable)
Desk top :
Marble
Usage :
Ear Nose Tthroat Examination
Description

Ear Nose Tthroat ENT Examination Unit , Clinic Modern Medical Instruments

Standard Equipment
Desk top 1pc
Compressor pump 1pc
Suction vacuum pump 1pc
Main suction apparatus 2pcs
Larynhoscope preheater 2pcs(Time is adjustable)
projection lamp (LED) 2pcs
Computer 1pc
Image processing system software 1pc
Printer 1pc
Cold light source (LED) 1pc
Monitor (LED) 1pc
CCD camera 1pc
X-ray viewer (LED) 1pc(optional LED)
Endoscope 3pcs
Sprayer 6pcs(curved 2pcs,straight 4 pcs)
Suction device 2pcs
Tray 2pcs
Cotton can 2pcs
Liquid medicine bottle 6pcs
Control panel 1pc
Technical Parameter
Desk top Marble
Positive pressure 2.5kg/cm2 (Optional imported parts)
Negative pressure 740mmHg(max) (Optional imported parts)
Main suction apparatus 2500CC
Larynhoscope preheater 450W(adaptive control system,adjustable time)
LED projection lamp ≥8 W ; illuminate≥1×104
Sprayer Pressure: 0.1MPa～0.15MPa (adjustable)
Suction device ≥0.07MPa (adjustable)
Temperature 10℃～35℃
Voltage 220V
Frequency 50/60HZ
Optional:
Endoscope
Endoscope imaging system
Imaging management system
ENT operating chair
Doctor chair
Cold light source
Dimension
1655mm*730mm*885mm

Regular problems solving chart

Problems Problems cause Solving methods
1. Indicator light off; The system doesn’t work. Power is cut off

1. Check the power supply

2. Check the electrical wire

3. Check the fuse

4. According situation to repair or replacement
2. Power supply works well; positive pressure and negative pressure can’t work.

1. Pump doesn’t work

2. Gas is leak

1. Check the positive pressure, negative pressure and gas pump

2. Check the pipe

3. Check the pressure adjuster

4. According situation to repair or replacement
