6KG Pain Relief Would Healing Red Light Therapy Equipment Improving Immunity

Description:

Red Light Therapy Instrument uses the new light brightness LED light-emitting could light source,which is the same as the new advanced technology of LED red light photodynamic.It emit specific low-energy red light radiation.Red light energy is capable to penetrate body deeply more than 120nm.Our Red-Light Therapy Instrument output power is more than 2w and easy to operation.

Main Applications:

1) The Red-Light Therapy is used on inflammation,pain.Have inflammatory analgesic effect on boil,carbuncle,shingles,mastitis and sote tissue injury.

2) Promote ulcers and bed sores wound healing

Features:

The instrument uses digital control circuit. all touch button and digital display.It is very accurate.

The Red-Light Therapy can have potochemical effect on organisms and cell,thus producing biological effects and therapeutic effects. Most red light is absorbed by the mitochondria of red cell.After red light irradiation,mitochondria’s peroxidase activity increased,so that cell metabolism increased,make the glycogen content increased,and also protein synthesis and ATP breakdown increased.Thereby strenghthen the newborn of cells,Promote wound healing,at the same time,increased the leukocyte phagocytosis.Improve immunity. The red light have great penetrating power on human body,have effect on inflammation,swelling,pain and so on.

Technique Parameters:

1) Center Wavelength:620nm~640nm;

2) Export power:2-3W

3) Maximum Export:4.8mW

4) Irradiation diameter:100mm from light,diameter >90mm

5) Time setting:1—99min；range :1 min；±10%

6) Rate Power:200W

7) Fuse specifications:2A

Working Conditions:

a)Temperature:5℃～40℃；

b) Relative humidity: 30%～80%;

c) Barometric: 780～1060hPa；

d) Power supply: AC220V,50HZ

Maintenance:

1. Machine used in dry ventilated place,Not covere it.

2. Can not wipe machine with corrosive or disinfectant liquid.only wet towels.

3. Using the same size to replace damaged parts.

4. Change fuse: There are two pcs fuse underplat, One is in the supply socket,When replacement need take out lug, screwdriver below the socket to outward pry out the insert.The other one is near supply socket unscrew to the sounter-clockwise,In closed state,replace fuse with the same size (2A)

Transportation and Storage:

1. Transportation and storage condition

Temperature:-40℃～55℃

Relative Humidity:≤95%

Atmospheric Pressure:50Kpa～106Kpa

2. Before tranport the machine must be placed accroding to factory package (Suggest that don't shrow Original box and soft materials)

3. Must stored in non corrosive gas,well ventilated condition.Not press.Upward place the box.

4. After installation,only close-move and vertical transport,tilt less than 5 degree.
