LCD Digital Portable X Ray Machine Hand / Foot Surgery Imaging Scope Streamlined Design
LCD Digital Portable X Ray Machine Hand / Foot Surgery Imaging Scope Streamlined Design
LCD Digital Portable X Ray Machine Hand / Foot Surgery Imaging Scope Streamlined Design
LCD Digital Portable X Ray Machine Hand / Foot Surgery Imaging Scope Streamlined Design
Specifications
Brand Name :
STATEMED
Model Number :
STT13-PXM57
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
competitive
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
50 sets per month
Packaging Details :
carton, wooden case
Model :
STT-X-50S-F
Product Name :
Hand and foot surgery X-ray machine
Resolution :
≥31p/mm
Grayscale :
≥7 scale
Tube current :
0.25-0.5mA
Generator working frequency :
20Khz
Description

Low-Intensity Portable LCD Digital X Ray Imaging Scope X Ray Machine

General Description:

The 50mm LCD Portable X-Ray unit is a high frequency X-Ray Imaging Scope which is based on CCD sensors imaging princle. Model is a unique device combining radioscopy and radiography functions. It is equipped with small display transmitting images to the computer, which by means of simple software can be recorded to digital media or printed out. The unit is indispensable in traumatology and orthopaedics for emergency diagnostics. 50mm LCD Portable X-Ray Unit is widely used in the radioscopy for knee joint, ankle ,femoral shaft and other thick parts.

Application

  1. Fracture distal radius closed reduction, needle external fixation treatment
  2. Taking Foreign body from muscle
  3. Hospital orthopedics, hand and foot surgery, pediatrics, dental and so on
  4. Fieldwork, first aid site diagnosis
  5. Check contraceptive ring for birth control women

Features

1. Flexible and practical

  • Streamlined design
  • Light weight, suitable for carrying and use
  • One-click operation

2. Full Functioning

  • Digital LCD driver module, can freeze pictures, store video or screenshots, can connect the computer, storage or output through the printer
  • Built-in rechargeable battery, suitable for field operation
  • Using high-resolution capture card, about 400 thousand pixels

3. Stable and reliable

  • High-frequency PWM circuit design
  • High-strength ABS plastic body
  • High-definition imaging design

Parameter

Model STT-X-50S-F
Output Image size 50 mm
Survey Thinkness ≤300 mm
Tube current 0.25-0.5mA
X-ray tube voltage 45-70KV
Resolution ≥31p/mm
Grayscale ≥7 scale
Brightness ≥250lm/cm²
Generator working frequency 20Khz
Stand-Position Protection Area ≤0.33mGy/h
Power Consumption ≤200W
Power Supply AC220V±10%
Weight 3.45Kg
Size 120*525*360mm

Packing list:

1. X-Ray machine*1

2. Machine attachment:

Manual*1

Certificate*1

Warranty card*1

Power Adapter*1

Additional protection screen*1

Software CD*1

USB cable*1

LCD Digital Portable X Ray Machine Hand / Foot Surgery Imaging Scope Streamlined Design

X-Ray machine attachment:

LCD Digital Portable X Ray Machine Hand / Foot Surgery Imaging Scope Streamlined Design
