Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
Specifications
Brand Name :
STATEMED
Model Number :
STT13-PXM56
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
competitive
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
10 working days
Packaging Details :
carton, wooden case
Feature :
Low-Intensity
Size :
120*525*360mm
Weight :
3.45Kg
Product Name :
Stomatology Equipment
Stand-Position Protection Area :
≤0.33mGy/h
Tube current :
0.25-0.5mA
Description

Hand and Foot Surgery Digital Portable X Ray Imaging Scope X Ray Machine

Working principle

The 50mm LCD Portable X-Ray Unit is a high frequency X-Ray Imaging Scope which is based on CCD sensors imaging princle. Model is a unique device combining radioscopy and radiography functions. It is equipped with small display transmitting images to the computer, which by means of simple software can be recorded to digital media or printed out. The unit is indispensable in traumatology and orthopaedics for emergency diagnostics. 50mm LCD Portable X-Ray Unit is widely used in the radioscopy for knee joint, ankle ,femoral shaft and other thick parts.

Application

  • Taking Foreign body from muscle
  • Fracture distal radius closed reduction, needle external fixation treatment
  • Hospital orthopedics, hand and foot surgery, pediatrics, dental and so on
  • Fieldwork, first aid site diagnosis
  • Check contraceptive ring for birth control women

Features

1. Flexible and practical

  • Streamlined design
  • Light weight, suitable for carrying and use
  • One-click operation

2. Stable and reliable

  • High-frequency PWM circuit design
  • High-strength ABS plastic body
  • High-definition imaging design

3. Full Functioning

  • Can be directly connected to the computer, stored or output through the printer
  • Built-in rechargeable battery, suitable for field operation
  • High-resolution capture card

Parameter

Model STT-X-50S-D
Output Image size 50 mm
Survey Thinkness ≤300 mm
Tube current 0.25-0.5mA
X-ray tube voltage 45-70KV
Grayscale ≥7 scale
Resolution ≥31p/mm
Brightness ≥250lm/cm²
Generator working frequency 20Khz
Stand-Position Protection Area ≤0.33mGy/h
Power Consumption ≤200W
Power Supply AC220V±10%
Size 120*525*360mm
Weight 3.45Kg

Packing list:

1. X-Ray machine*1

2. Machine attachment:

a) Manual*1

b) Certificate*1

c) Warranty card*1

d) Power Adapter*1

e) Additional Protection Screen*1

f) Software CD*1

g) USB Cable*1

Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment

Low Intensity Portable X Ray Machine Hand And Foot Surgery Stomatology Equipment
