Specifications
Brand Name :
Xiangteng
Model Number :
XT-SLG-RD
Certification :
BIS CE
Place of Origin :
China
MOQ :
2000pcs
Supply Ability :
5000pcs/day
Delivery Time :
30 days
Packaging Details :
color box, standard export carton
Wattage :
5W 9W 15W 22W
Warranty :
2 years
Body Materials :
Aluminium , Plastics
Is Dimmable :
No
Use :
Indoor Lighting
Luminous Flux :
1200lm
Description

5W 9W 16W 22W LED Recessed Ultra Thin Ceiling LED Light Retrofit Panel Slim

Our product is super easy to install, and requires only 2 inches of clearance, due to the Ultra Thin design ! the product is vapor proof so it is safe to use in damp locations including bathrooms , hospitals , hotels , homes , stores , etc

We have designed our product to be the most high-end state of the art panel on the market . Our LED light will also help you save on your electricity bill ! Switching over from traditional fluorescent fixtures can save you up to 90% on your energy usage

Product Usage

This high-quality panel light comes with a stylish and slim design . It is fitted with reliable LEDs to ensure high performance and low energy consumption .

This LED panel light is suitable for office conference room , lecture hall , reception room , supermarket , shop etc

Product Specifications

• SLIM LED panel light.
• Luminous efficacy : 80lm/W.
• Color temperature : 3000K , 4000K , 5000K , 6000K
• PF : >0.5
• CRI : >80.
• External driver.

5W 22W Ultra Thin SMD Panel Lights , Ceiling Retrofit Slim Square SMD Led

Advantages

• New model panel series designed specially for good quality at very competitive prices
• Cable terminal is anti drag , easy dissasembly , and conveniet appliabie safety

• Double spring design , rich elasticity and easy to install

• Thermal conductivity nylo back plate, fast heat dissaption

• Aopts narrow bezel design , with light leakage prevention design

• Easy installation. Can be easily fitted instead of ordinary recessed light fixture

Technical Data

Item No. XT-SLG-SQ
Dimension (mm) 85*85*20 120*120*20 170*170*20 225*225*20
Opening Size (mm) 75*75 110*110 155*155 210*210
Wattage 5W 9W 15W 22W
Input Voltage AC85~265V
Current 260-280mA or 280-300mA
Luminous flux 70~90lm/W
Light source SMD2835
Material Aluminium + PP+Thermal Conductiivity Nylon
Color rendering index >80
Driver Insolated Driver / BIS Driver
Color temperature 3000k-3500K / 4000K~4500K / 6000K~6500K
Light color Warm white / Neutral white / Cool white
Working temperature ‘-20℃±45℃
Beam angle 120 º
IP code IP44
Life span 40000 Hours
Warranty 2 years
MOQ 500 pcs /item

Application

* Beautiful decoration to make life more enjoyable

* Living room , bedroom , kitchen , bathroom

* Conference , meeting room , showroom , showcase

* School , university , hospital , hotel

* Supermarket , department store or even more
