White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
White Finish Round Panel 8000K 6W Recessed LED Ceiling Light
Specifications
Brand Name :
XENTER
Model Number :
XT-AL-SQ-24W
Certification :
BIS CE RoHS IP65
Place of Origin :
China
MOQ :
500pcs
Supply Ability :
5000pcs/day
Delivery Time :
25-30 days
Packaging Details :
color box, standard export carton
Finish Color :
White
Power :
24w
CCT :
3000K 4000K 6500K 8000K
Item Type :
Ceiling Lights
Color Rendering Index :
Ra>70
Lamp Body Materials :
Die Cast Aluminium
Description

6W Recessed LED Ceiling Light with Glare Control White Finish Round Panel

About Anti Glare Panel Light

It is an exciting new recessed lighting development which breaks the conventional mold.

Using innovative die cast aluminium materials and geometry, it brings a new approach to office and area lighting design. Its unique diffuser system brings life and vitality to every space. With its seemingly ‘variable’ geometry effect, excellent luminance and glare control compliance, it is now the optimum solution.

With high level of geometric distribution adds to the lighting quality of a typical space. It achieves high levels of illuminance across vertical as well as horizontal planes, remaining true to the principals of glare and luminance control.

Technical Descriptions:

• CCT: 3000K/4000K/6500K
• Wattage: 6W

• Luminous Flux: 320lms
• Side Emitting
• PF: >0.5

• Work Voltage: AC85-265V
• Color Rendering Index: >70
• Installation: Recessed

Product Specifications

Shape

Watt

Housings

Driver

Voltage

PF

CRI

 Dimension
(mm)		 Cutout
(mm)

Round

 6W

Die Cast

Aluminium

Isolated

85-265V

0.5

≥70

 ø90 ø75
12W ø120 ø100
18W ø170 ø150
22W ø225 ø200

Square

 6W

Die Cast

Aluminium

Isolated

85-265V

0.5

≥70

 90*90 75*75
12W 120*120 100*100
18W 170*170 150*150
22W 225*225 200*200

Packing Information

Commodity Description

Shape

Watt

PCS/CTN

CTN Size
(cm)

Warranty

Anti Glare Panel Light

Round

 6W 50 52.5*21*28.5

2 years
12W 50 65*20*33
18W 20 39*20*44
22W 20 48*20*55

Anti Glare Panel Light

Square

 6W 50 52.5*21*28.5

2 years
12W 50 65*20*33
18W 20 39*20*44
22W 20 48*20*55

White Finish Round Panel 8000K 6W Recessed LED Ceiling Light


Applications For

1. General room lighting in ceilings, suspended ceilings
2. Interior lighting such as office, bed room, class room, study room, super market, store, wareshouse
3. Coffered ceiling lighting
4. Cabinet lighting
5. Lobby lighting
6. Sculpture and statue illumination


Warnings

1. Cut off the power before installation
2. Can't be used as emergency light
3. To keep them away for the flammable objects.
4. The environment temperature of the lamp operation: -20Ċ to +60Ċ
5. Do not try to open this unit , they are sealed completely
6. To install it by professional electrician
