Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp
Specifications
Brand Name :
XENTER
Model Number :
XT-WBYX-36W
Certification :
BIS CE RoHS IP65
Place of Origin :
Guangdong China
MOQ :
500pcs
Supply Ability :
5000pcs/day
Delivery Time :
25-30 days
Packaging Details :
color box, standard export carton
Model :
Frameless Panel Lamp
Wattage :
36 watts
Input Voltage :
AC85-265V / AC175-265V
Dimmension :
Dia: 225mm
Cut-out :
Dia: 75-210mm
IP Rate :
IP20
CCT :
2700K-8000K
Driver :
Isolated / Non Isolated
Beam Angle :
180 degrees
Dimmable :
No
Frame Color :
White
Description


Frameless 36W Round Adjustable Cut-Out LED Panel Light Backlit Ceiling Lamp

Product Description

• Frameless adjustable indoor lamp , wide beam angle 180º , perfect indoor lighting

• Die cast Aluminium case with fine workmanship on the back side, nice heat dispation
• Adjustable hole size(cut out) from 75mm to 210mm, no need to to worry about cutting hole size, easy installation.
• Separate driver , easy to replace
• Back lit panel design, light brightness more than 3500 lumens,

• Perfect design to replace any damaged ceiling lamps completely very soon, just ignore the existing cut hole size



Product Specification

Wattage 36W
Installation Type Concealed
Lamp Shape Round
Dimmension (D*H) Ø225mm*H40mm
Cut Out Size Ø75-210mm
Work Voltage AC85-265V / AC175-265V
Lamp Type LED SMD
Base Materials Die Cast ALuminium
Diffusor Material High Quality PP
Luminous Efficiency 100lm/w
Lamp Lumens 3500 lumen
IP Rate IP20
Frequency 50/60Hz
LED Driver Isolated / Non Isolated
Power Factor >0.5
Colour Rendering Index (CRI) Ra>70/80
Dimmable Non-Dimmable
Colour Temperature 3000K 4000K 6000K 8000k, Bi Color
Beam Angle 180º


Round Adjustable Cut - Out Frameless LED Panel Light 36W / Backlit Ceiling Lamp


Lighting Application

LED panel light is a high-grade indoor lighting lamps, its outer frame is made of aluminum alloy anodized, the light source is LED, the whole lamp design is beautiful and simple, luxurious atmosphere, not only good lighting effect, but also can give people the feeling of beauty.
LED panel lamp design is unique, the light after the high transmittance of the light guide plate to form a kind of uniform plane luminous effect, illumination uniformity is good, the light is soft, comfortable and bright, can effectively alleviate eye fatigue.LED panel lights also protect against radiation and do not irritate the skin of pregnant women, the elderly or children.


Warnings

1. Cut off the power before installation
2. Cant be used as emergency light
3. To keep them away for the flammable objects.
4. The environment temperature of the lamp operation: -20Ċ to +60Ċ
5. Do not try to open this unit , they are sealed completely
6. To install it by professional electrician
