Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W
Specifications
Brand Name :
XENTER
Model Number :
XT-CYWB-10+4W
Certification :
BIS CE RoHS IP65
Place of Origin :
China
MOQ :
500pcs
Supply Ability :
5000pcs/day
Delivery Time :
25-30 days
Packaging Details :
color box, standard export carton
Rated Watt :
10+4W
Light Style :
Back Lit
Materials :
Punch Stamp Aluminium
Voltage :
AC85-265V
Luminous Efficiency :
100lm/w
Light Source :
SMD 2835
CRI :
>70/80
PF :
>0.5
Description

Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W



Product Advantages

• Back lit Bi color panel light, super bright

• Junction panel light, can replament the exist panels freely, no need to worry about cut hole size

• Frameless design, large light space

• Power : 5+3W, 10+4W, 12+6W, 30+6W

• Color combination: white+blue, white+green, white+pink, white+red, white+WW, white+PGB

• Adjustable cut hole size from Ø45-105

Adjustable Frameless Round Concelled Bi Color LED Panel Light 10+4W

Color Combination WH+BL, WH+GR, WH+WW, WH+RD, WH+PK, WH+PGB
Rated Wattage 10+4W
Mount Type Concealed / Surface
Shape Round /Square
Dimmension (mm) Ø190*30
Work Voltage AC85-265V
Lamp Type SMD2835
Housing Materials Die cast Aluminium
Frequency 50/60Hz
LED Driver Isolated
Power Factor >0.5
Colour Rendering Index (CRI) Ra>70
Warranty 2 years



Round Adjustable Frameless Dual Color Concealled LED Panel Light Specification

Shape Watt Driver Voltage Dimension
(mm)

Cut Out

(mm)

 PCS/CTN CTN Size
(cm)

Round

 5+3W

Isolated

AC85-265V

 ø85 Ø45-80 50 69.5*22*26
10+4W ø120 Ø45-105 40 42*35*33
22+6W ø170 Ø45-155 20 42*23*42
30+6W ø220 Ø45-205 20 45*44.5*24

Adjustable Rimless Round Bi Color Back Lit LED Panel Light White+Pink 10+4W

Lighting Applications

1. General room lighting in ceilings, suspended ceilings

2. Interior lighting such as bed room, class room, study room, super market, store, wareshouse

3. Coffered ceiling lighting

4. Cabinet lighting

5. Lobby lighting

6. KTV, hotel ,restaurant, bars, museum, movie theater etc


Warnings

1. Cut off the power before installation
2. Can't be used as emergency light
3. To keep them away for the flammable objects.
4. The environment temperature of the lamp operation: -20Ċ to +60Ċ
5. Do not try to open this unit , to have the professional person to open it
6. Internal lighing only, can be used outside lighting
